HARDWARE CONFIGURATION

3.1

Front View

Figure 3-1 shows the main components and connectors from the front side of NuMaker-IoT-MA35D1-
A1 board.

Target Chip (U1): MA35D16F987C (LQFP216) MCP package with DDR3L (512MB).
RGMII0 Gigabit PHY
& Transformer
(U14, RTL8211FDI)
(U15, GST5009BM)
RMII1 10/100 PHY
& Transformer
(U16, RTL8201FI)
(U17, TS8121C)
NUC123 ICE
Interface
(J9)
USB0_ID
Connector
(J10)
VCOM Controller
(U19, NUC123ZD4AN0)
HSUSB1
Host
(CON11)
HSUSB0
Host/Device
(CON10)
CAN_1
Transceiver &
Connector
(U7, J2)

Figure 3-1 Front View of NuMaker-IoT-MA35D1-A1

3.2

Rear View

Figure 3-2 shows the main components and connectors from the rear side of NuMaker-IoT-MA35D1-A1
board.
Oct. 31, 2022
Target Chip
(U1, MA35D16F787C)
Raspberry Pi
Connector
(CON4)
LEDs
USB VCOM Port Key Buttons
(CON9)
RS232_10
RS485_12
Transceiver &
Transceiver &
Connector
Connector
(U8, J5)
(U9, J6)
Page 9 of 43
NuMaker-IoT-MA35D1-A1
NAND Flash
(U12, W29N08GVSIAA)
CCAP0
QSPI0 SPI-NAND Flash
Connector
(U11, W25N04KVZEIR)
(CON3)
RTC Battery
SWJ
Connector
Connector
(J1)
(CON12)
SWJ_nRESET
Audio codec
Connector
(U18, NAU88C22)
5V/2A
Power Jack
(CON2)
RTC Wakeup Key
(SW1)
Power-on Setting
DIP Switch
(SW7)
Headset Jak
(CON8)
Speaker
Connector
(J7)
Microphone
(M1)
Reset Key
(SW2)
(J3)
Rev 1.01
