FEATURES


Target Chip: MA35D16F987C (LQFP216) MCP package with DDR3L (512 MB), which can
run up to 800 MHz

Power:
5V/2A Power Jack, USB VCOM Port or HUSB0 Device
–
Battery header for RTC power
–

Debug:
UART0 debug port: USB Virtual COM (VCOM) port
–
Debug ports: SWJ (JTAG + SWD) connector
–

Memory Devices
An on-board Quad SPI NAND Flash device (512 MB)
–
An on-board NAND Flash device (1 GB)
–
MicroSD memory card (SD1, supports SD3.0)
–

One power-on setting DIP-Switch for evaluation booting source selection

One set of Gigabit Ethernet port: One Gigabit Ethernet (RGMII) PHY device, transformer
and RJ45 port connector

One set of Megabit Ethernet port: One Megabit Ethernet (RMII) PHY device, transformer
and RJ45 port connector

Two sets of high speed USB ports: One Host/Device port and one Host port

One Raspberry Pi 40-pin header connector

Arduino UNO Compatible Extension Connectors

One camera capture (CMOS sensor) header connector

One audio codec with microphone input and speaker output

One set of RS232 transceiver and header connector

One set of RS485 transceiver and header connector

One set of CAN FD transceiver and header connector

Four user key buttons

Three user LEDs
