Summary of Contents for Thermo Scientific 2032

  • Page 1 Models: 2032 and 2036 Forma Plasma Thawing Bath Operating and Maintenance Manual Manual No: 7002032 Rev. 6...
  • Page 2 The material in this manual is for information purposes only. The contents and the product it describes are subject to change with- out notice. Thermo Scientific makes no representations or war- ranties with respect to this manual. In no event shall Thermo be held liable for any damages, direct or incidental, arising out of or related to the use of this manual.
  • Page 3 Model 2032 and 2036 Baths ____________________________________________________________________ Important operating and/or maintenance instructions. Read the accompanying text carefully. Ce symbole attire l'attention de l'utilisateur sur des instructions importantes de fonctionnement et/ou d'entretien. Il peut être utilisé seul ou avec d'autres symboles de sécurité. Lire attentivement le texte d'accompagnement.
  • Page 4 We can also provide you with a quotation on our Extended Warranty for your Thermo Scientific products. Whatever Thermo Scientific products you need or use, we will be happy to discuss your applications. If you are experiencing technical problems, working together, we will help you locate the problem and, chances are, correct it yourself...over the telephone without a service...
  • Page 6: Table Of Contents

    Model 2032 and 2036 Baths ____________________________________________________________________ Table of Contents Section 1 - Receiving ......2 - 1 1.1 Preliminary Inspection .
  • Page 8: Section 1 - Receiving

    2.1 Features This item was thoroughly inspected and carefully packed The Model 2032 Thawing Bath is designed to thaw from prior to shipment and all necessary precautions were taken to 1 to 8 plasma units in 25 minutes, or 4 red cell units in about 12 ensure safe arrival.
  • Page 10: Section 3 - Installation And Start-Up

    Model 2032 and 2036 Baths ________________________________________________________Installation and Start-Up 3.5 Connecting to Power Section 3 - Installation and Start-Up With the main power OFF, connect the bath to an adequate power source. See the electrical data plate mounted on the unit 3.1 Location...
  • Page 12: Installing The (Optional) Red Cell Canister Rack

    Model 2032 and 2036 Baths ___________________________________________________________Control Panel Operation 3.9 Installing the (Optional) Red Cell Canister Rack Section 4 - Control Panel Operation WARNING! The Red Cell canister must be used 4.1 Main Power Switch and Indicator Light when thawing red cells. Red cells will suffer heat...
  • Page 14: Mechanical Timer

    Model 2032 and 2036 Baths ______________________________________________________________Routine Maintenance 4.4 Overtemp Safety Thermostat and Temp Safety Section 5 - Routine Maintenance Indicator Light The overtemp safety thermostat should be set slightly 5.1 Cleaning the Bath above the operating temperature of the bath. In the event of an overtemp condition, the overtemp safety thermostat will: 1.
  • Page 16: Cleaning The Pump

    Model 2032 and 2036 Baths ________________________________________________________________________Service 5.2 Cleaning the Pump Section 6 - Service (For Qualified Service Personnel) Special cleaning of the pump may become necessary. To remove the pump for cleaning, unplug the pump and remove the 4 screws securing it. The pump can then be lifted out of the De-energize all potential sources of energy to this bath.
  • Page 18: Replacing The Temperature Probe

    Model 2032 and 2036 Baths ___________________________________________________________________Specifications 6.3 Replacing the Temperature Probe Section 7- Specifications 1. Drain the bath. See Section 3.4. Description Models 2032 and 2036 2. Open the control access door and locate the temp probe Operating Temperature mounted through the wall of the control area and +5°C above ambient to +60°C (+140°F) ±0.4°C...
  • Page 20: Section 8 - Parts List

    Model 2032 and 2036 Baths _______________________________________________________________________ Parts List Section 8 - Parts List Stock # Description 56005 Mounting clip 285798 Outlet, snap-in, 3 wire 515060 Bearing, flanged nylon 5/16 ID 280004 #312 Green pilot light 280006 #312 Amber pilot light...
  • Page 22 Model 2032 and 2036 Baths ______________________________________________________________ Electrical Schematics 9 - 1...
  • Page 23 Model 2032 and 2036 Baths ______________________________________________________________ Electrical Schematics 9 - 2...
  • Page 26 Thermo Scientific Controlled Environment Equipment 401 Millcreek Road, P.O. Box 649 Marietta, Ohio 45750 U.S.A. Telephone (740) 373-4763 Telefax (740) 373-4189...
