codelocks
KL1200 - Vertical Programming & Operating
Instructions
Codes - The Basics
• The KitLock has four code levels available:
i) Master Code
ii) Sub-Master Code
iii) User Code
iv) Technician Code
• The KitLock is supplied with two factory set codes:
Master Code: 11 33 55 77
User Code: 22 44
• When fitted immediately change the Master Code and User Code.
• All Master Codes and Sub-Master Codes are 8 digits long.
• All User Codes are 4 digits long.
• All Technician Codes are 6 digits long.
• The lock 'open' time is set at 4 seconds.
Functions
Before programming select the most appropriate function for the application.
A) PRIVATE USE
Important Note: This is the default function and is already pre-programmed in new locks.
This is the most common function and is used where
the same code will be repeatedly used.
B) PUBLIC USE
Advertisement
Table of Contents
Related Manuals for CODELOCKS KL1200
Summary of Contents for CODELOCKS KL1200
- Page 1 KL1200 - Vertical Programming & Operating Instructions Codes - The Basics • The KitLock has four code levels available: i) Master Code ii) Sub-Master Code iii) User Code iv) Technician Code • The KitLock is supplied with two factory set codes:...
-
Page 2: Operating Instructions
The user enters their own personal four-digit code. This locks the lock. The same code is entered to open the lock before being erased and ready for the next new user. This function is used for short term, multi occupancy applications, e.g. a locker in a leisure centre ... - Page 3 • Open the lock in Technician mode without erasing User Code when in B) Public Use Function. The same code cannot be programmed into more than one level. LOST CODE PROCEDURE Note: The procedure requires the door to be open. •...
- Page 4 The procedure is as follows: • Place the contact points of the PP3 battery against the contact points at the base of the lock, making firm maintained contact. • The positive + PP3 terminal against the + contact on the lock, and the negative – PP3 terminal against the negative contact on the lock.
- Page 5 Master Code Commands CHANGE THE MASTER CODE #Master Code • 01 • New Master Code • New Master Code •• Example: #11335577 • 01 • 12345678 • 12345678 •• Result: Master Code has been changed to 12345678. Note: # prefix not required when in B) Public Use. SET OR CHANGE THE USER CODE #Master Code • 02 • User Code ••...
- Page 6 SET OR CHANGE THE SUB-MASTER CODE #Master Code • 04 • Sub-Master Code • Sub-Master Code •• Example: #11335577 • 04 • 22446688 • 22446688 •• Result: Sub-Master Code 22446688 now operative. Note: # prefix not required when in B) Public Use. DELETE THE SUB-MASTER CODE #Master Code • 05 • 05 •• Example: #11335577 • 05 • 05 •• Result: Sub-Master Code deleted. Note: # prefix not required when in B) Public Use. ...
- Page 7 1. When the lock is opened the User Code will be erased and ready for the next new user to enter their code. 2. When locked in B) Public Use Function the • LED will flash every two seconds indicating locked status. 3. Keypad in this function is only active when lever is in closed position. ...
- Page 8 To disable the sounder enter the following toggle code string: #Master Code • 14 • 14 •• Result: No sound when buttons pressed. To enable the sounder repeat above code sequence. POI-KL1200- v2:0813 © 2019 Codelocks Ltd. All rights reserved. https:/ /www.codelockssupport.com/portal/kb/articles/kl1200-vertical-programming-operating-instructions...
