M The Tablet PC has a Dual Head Video Controller that lets you mirror the
IRRORING OR
E Tablet PC display or extend it to a second monitor or external device, such
XTENDING
Y D
as a projector.
OUR ISPLAY

Connecting the External Monitor/Data Projector and Tablet PC

Setting Up a Mirrored Desktop

1. Plug the VGA monitor cable into the VGA port on the Tablet PC or
Motion FlexDock.
2. Then, connect the external monitor or data projector to a power outlet
and turn it on. Windows XP will recognize the external monitor or data
projector and search for a driver.
3. If necessary, install the driver from the CD supplied by the monitor's
manufacturer.
Use this feature to connect an external projector for presentations.
1
Mirrored Desktop Example: (1) Word Documents; (2) Tablet PC; (3) External
Monitor
NOTE: The resolution of the external monitor will be the same as the Tablet PC
display.
a. Open the Motion Dashboard.
b. Select the Mirror Desktop
radio button under External
Display. This setting
automatically creates an identical
display on the external monitor.
NOTE: You may also set up this
feature through the Intel(R) Extreme Graphics icon, shown here
(found in the Windows Control Panel or in the System Tray at the
bottom right of the Tablet PC display).
Chapter 4 Using Your Motion Tablet PC
2
3
Motion Computing Tablet PC User Guide 46
1
