Table 2-1 Tablet PC LEDs, Buttons, Connectors, and Other Components
1 Pen holder
2 Power LED
3 Battery LED
4 Hard Disk Drive LED
5 Wireless LED
6 Escape button
7 Function button
8 Five-way directional
control button
9 Hot Key #1
10 Hot Key #2
11 Security button
12 Microphone
13 Pen tether post
14 PC card slot
15 Antenna cover
16 Power switch
17 AC power jack
18 RJ-11 modem port
19 RJ-45/LAN
20 RJ-45 LEDs (2)
21 VGA connector
22 Docking connector
23 USB ports (2)
24 IEEE 1394 port
25 Audio-in/Microphone
26 Audio-out/Headphone Input jack for a 3.5mm plug for a headset; mutes the built-in speakers
27 Speakers (2)
28 Product identification
29 Battery release latch
30 Battery
31 Battery gauge
32 Hard drive bay
33 Memory/mini-PCI
access
34 Security lock slot
Storage bay for the Motion Digitizer Pen
Displays power status
Displays battery status
Displays Hard Disk Drive (HDD) activity
Displays wireless activity and on/off status
Primary function (not programmable): Esc. Secondary function (programmable): Alt+Tab
Press this Function button + another button to activate Secondary functions
Primary functions (not programmable): Scrolls Up/Down/Right/Left + Enter
Secondary functions (programmable): Left arrow—Shift+Tab; Right arrow—Tab; Up
arrow—Page Up; Down arrow—Page Down
Primary function (programmable): Displays the Motion Dashboard
Secondary function (programmable): Opens the Microsoft Windows Journal
Primary function (programmable): Changes the Tablet PC display orientation
Secondary function (programmable): Opens the Tablet PC Input Panel.
Primary function: Ctrl-Alt-Del; Secondary function: None
Works at a natural distance; disabled when an external microphone is plugged in
Post to which you can secure the Pen by means of a plastic loop
Holds one Type-II PC card for networking, memory expansion or accessory connections.
A plastic blank ships in this slot in the Tablet PC; leave this installed when not in use.
802.11 wireless networking antenna cover; this area does not open
Turns the Tablet PC on and off; can configure to activate Hibernate or Stand By modes
Connects to the Motion AC Adapter through a right-angled connector on the Adapter. Use
only a Motion AC Adapter with the Tablet PC.
Connector for a 56.6K V.90 modem
Standard RJ-45 connector for a 10/100 Mbps network
Display LAN connection status; blink green/amber for a connection
A standard DB-15 monitor connector for an external monitor
Docks with the Motion FlexDock
Stands for Universal Serial Bus; a port connect for connecting USB devices, such as a
mouse, printer, or digital camera
Connects 4-pin accessories, such as DVD players, optical disc drives, video cameras and
other electronics
Input jack for 3.5mm plug for a microphone
Integrated speakers that mute when you connect a headset or external speakers
Serial numbers and system certifications marks and labels
Latch that releases the battery from the battery bay
Self-monitoring battery tracks the amount of charge
Displays the battery's charge
Bay that houses the HDD; 20GB HDD memory (standard); optional 40GB and 60GB
capacity
Bay that houses the memory modules and mini-PCI card; 256MB memory (standard),
upgradeable to 1GB
Fits a cable lock for securing the unit to a desk, etc.
