LED
Steady green Battery 100% charged
(AC plugged in)
Steady amber Battery charging
(AC plugged in)
Steady red Battery overheated or defective Wait for the battery to cool.
Flashing green and Battery discharging abnormally Replace the battery.
amber
Slow-flashing amber 10% battery charge remaining
(AC unplugged).
NOTE: When the remaining battery charge is 10%, the Tablet PCs issue a Low
Battery alarm message in addition to the LED warning. For information about
modifying this alarm (you can set it to display a message or to produce an audible
warning), see Chapter 4 of this User Guide.
Fast-flashing amber 3% battery charge remaining
(for only a few (AC unplugged)
seconds)
NOTE: Hibernate mode attempts to save data in any open programs to your Hard
Disk Drive. When you restart the Tablet PC, it returns to the same system status as
before hibernation.
Off Tablet PC is unplugged from
AC power and the system is
running on battery power.

Battery Status Gauge

A five-LED battery gauge is located on the battery on the bottom of
the Tablet PCs. Each LED represents about 20% of available power.
You can activate the gauge by pushing the black button next to the
LEDs.
In the example shown here, two LEDs are lit, which means the
battery has about 40% of its power remaining.
Chapter 2 Motion Tablet PC Hardware
Table 2-4
Front Panel Battery Status LED
Battery Status
Motion Computing Tablet PC User Guide 17
Action
None
None
Replace the battery.
Immediately charge the
battery to avoid loss of data.
The Tablet PCs issue a
Critical Battery alarm and
automatically goes into
Hibernate mode.
Plug the Tablet PC into AC
power if you want to
preserve battery power.
