F P The front panel of the Motion Tablet PC contains six buttons, shown in
RONT ANEL
B Table 2-2. Most of these buttons have both primary and secondary functions.
UTTONS
In addition, some may be re-programmed for other functions.
M The Motion Tablet PC modem and LAN (network connection)
ODEM
LAN
communication ports are found on the connector edge, as shown below.
AND
C
ONNECTORS
Button
2 Same as keyboard Esc key
Escape
3 Function + other button
Function
activates secondary function
Five-way Works like the arrow keys
Directional Control on a keyboard. The center
2 of the button works like the
Button
Enter key.
1 & 2 Opens the Motion Dashboard.
Hot Key #1
1 & 2 Rotates the display.
Hot Key #2
Opens the Windows Task
3
Security
Manager (Ctrl + Alt + Del). Also
used for domain authentication
or logon screen.
1
NOTE: Primary function programmable.
3
Not programmable. For information about programming buttons, see Chapter 4.
1
2
3
Modem and LAN Connectors: (1) RJ-45 LEDs; (2) RJ-11
Modem; (3) RJ-45 LAN
NOTE: The Motion FlexDock has no built-in modem port. When using a
FlexDock, you must connect to the modem port on the Tablet PCs through the
FlexDock opening designed for this purpose.
• Modem (RJ-11 port) — Built-in, V.90 modem that operates at a
maximum of 56.6K throughput and has fax capabilities; port supports
a standard phone cord connector; connect the modem only to an
analog telephone jack, not to a digital telephone (PBX) network jack
• Ethernet LAN (RJ-45) — Connects a network, cable modem, or
xDSL; contains two status LEDs
CAUTION: Do not plug a standard RJ-11 phone cord into the RJ-45
port or you may damage the RJ-45 LAN port.
Chapter 2 Motion Tablet PC Hardware
Table 2-2
Default Button Functions
Primary Function
2
Secondary function programmable.
Motion Computing Tablet PC User Guide 15
Secondary Function
(Press Function + this button)
Equivalent to Alt + Tab
None
Left arrow = Shift+Tab
Right arrow = Tab
Up arrow = Page Up
Down arrow = Page Down
Opens the Windows Journal.
Opens the Tablet PC Input Panel.
None
