The data listed below is for reference purpose only, and indicate potential starting conditions. It is
the responsibility of the site operation manager to determine correct application requirements.
These are only starting points. They will vary with application and work piece condition.
Material or Application Type
Thin Walled Workpieces
Oblique Entry / Curved Surfaces
Semi-Circles / Fragile Setups
Soft / Gummy Materials
Typical / Average Applications
Deep Holes
Difficult-to-machine materials will require reduced feed rates.
Feed per Tooth (mm)
0.0254 / 0.0508 (0.0762 FPT with
Work Hardening Marerials)
0.1016 / 0.127
0.0762 / 0.1016
0.1016 / 0.127
27
