Rotabroach Element 40 PERM Manual page 20

Item No. Rotabroach P/N
8.16 RDB4002
8.17 RDB3049
8.18 RDB3043
8.19 RDB3050
8.20 RDB3047
8.21 RM17134
8.22 RDB2022
8.23 RDB3046
8.24 RDB3048
8.25 RDB4004
8.26 RDB4005
8.27 RDB2010
8.28 RD43305
8.29 RD43306
8.30 RDB2018
8.31 RD43310
8.32 RDB3031
8.33 RDB3006
8.34 RD45522
8.35 RDB3060/3(230V)
8.36 RDB3060/1(110V)
8.37 RD43603
8.38 RDB3069
8.39 RD43625
RDB3061/3(230V)
8.40
RDB3061/1(110V)
8.41 RDB3065
8.42 RDB3068
8.43 RDB5002
8.44 RDA5018
8.45 RDA3069
8.46 RD35617
8.47 RD45613
8.48 RDA4034
8.49 RD33616
8.5 RDB3066
8.51 RD33614
8.52 RDB5003
8.53 RDA4035
20
Description
Washer
Helical gear 31T 1.25M 15HA 30PA
17 tooth gear
Key steel 4×4×16
Gear axel
Rolling bearing 608
Dual gear
Gear axel
Key steel
Gear shaft washer 10mm ID
Needle bearing HK1010
Gear lever shaft
Rolling bearing 6003 RS
Circlip
Drive gear assembly
Circlip
Oil baffle plate
Gear plate
Rolling bearing 6001 RS
Inductor
Armature
Rolling bearing 629 RS
Bearing Sleeve
Tapping screw ST4.2×65
Field coil
Lead wire
Motor wire
Motor housing
Wire box cover
capacitor
Terminal
Screw M3×6 BTTN HD
Tapping Screw ST2.9×8
Brush cap
Brush
Brush hold
Top Cap
Tapping Screw
Qty/Pcs
2
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
2
1
2
1
1
1
1
2
4
4
2
2
2
1
2
