- Page 1 Sideboard Version:06/16/2022 1/14...
- Page 2 IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
- Page 3 Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size A x 9 B x 12 C x 12 D x 1 E x 2 4 x 35 mm 7 x 35 mm 15 x 9 mm...
- Page 4 4/14...
- Page 5 A x 4 4 x 35 mm Fix part 1 and 3 to part 2 using screw (A) Fit part 4 into groove between part 1.2 and 3. 5/14...
- Page 6 B x 4 D x 1 E x 2 4 x 16 mm 7 x 35 mm Insert quickfit screw (B) to panel 5. Secure handle (D) on to the assembled drawer using screw (E). C x 4 15 x 9 mm Insert cam lock (C) to panel 1 and 3.
- Page 7 F x 4 DL x 1 DR x 1 3.5 x 12 mm Carefully turn drawer upside down. Fix inner drawer runner (DR) to panel 1 and (DL) to panel 3 using screws (F) , as show. I x 20 J x 4 4 x 14 mm Fix leg plates (J) to part 8 using screw (I).
- Page 8 B x 4 F x 4 CL x 1 CR x 1 7 x 35 mm 3.5 x 12 mm Insert qucikfit screws (B) to part 6 and 7. Fix outer drawer runner (CL) to panel 6 and (CR) to panel 7 using screw (F) , as shown.
- Page 9 C x 4 K x 4 15 x 9 mm 6 x 30 mm Insert qucikfit wooden dowels (K) to part 6 and 7. Insert part 6 and 7 to part 9. Insert camlocks (C) to part 9 . Turm camlocks clockwise to tighten. 180°...
- Page 10 A x 4 K x 4 6 x 30 mm 4 x 35 mm Insert wooden dowels (K) to part 6 and 7. Fix panel 8 to part 6 and 7 unit using screws (A). B x 4 7 x 35 mm Insert qucikfit screws (B) and wooden dowels (K) to part 10.
- Page 11 C x 4 K x 4 15 x 9 mm 6 x 30 mm Insert camlocks (C) to part 6 and 7. Insert part 10 to part 6 and 7. Turm camlocks clockwise to tighten. 180° 11/14...
- Page 12 L x 12 2.5 x 14 mm Fix part 11 onto back of assembled unit using nails (L). Screw legs 12 into leg plates (J) as shown. 12/14...
- Page 13 Slide drawer into assembled unit. 13/14...
- Page 14 A x 1 M x 1 N x 1 O x 2 P x 1 6 x 30 mm 4 x 35 mm 3.5 x 14 mm For extra stability , it is recommended that you Please consider the wall fix your shelf to the wall using the additional mounting and fixing guide hardware ( A , M , N , O and P ) , as shown .
-
Page 15: Warranty Claims
WARRANTY WARRANTY CLAIMS •There is a 30-day warranty for broken furniture or any other problems that do not work properly. The warranty will start from the date of purchase which must be verified by proof of purchase. •Before making a claim, we may be able to answer your query, simply call us. Please leave your purchase order number, along with some details of the problem, if you want a replacement part. - Page 16 RETURNS CHANGED YOUR MIND AND NEED TO RETURN YOU ITEM? PLEASE FOLLOW THE BELOW INSTRUCTIONS: •If you have purchased and have simply changed your mind, follow the retailer’s instructions for returns. DEFECTIVE ITEMS •If your item is defective in any way, i.e. it doesn’t work but you can’t identify why, in the first instance, please consult our FAQ section at feedbackstation@163.com as there may be a simple solution to the issue.
