- Page 1 Display Stand 1/15 Version:09/23/2022...
- Page 2 IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
- Page 3 Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size Cx22 Dx20 Ø15x10mm Ø6x30mm Ø4x40mm Ø6x35mm Ex24 Ø4x14mm Ø3x12mm Mx24(+2) Nx16(+1) 3/15...
- Page 4 4/15...
- Page 5 Ø6x35mm Insert quickfit screw(A) into corresponding holes in No.9 plate with a screwdriver as shown. Ø15x10mm Ø6x30mm Connect No.10 with No.9 plate using wooden dowel(C) and turn cam lock(B) clockwise to tighten as shown. 5/15...
- Page 6 Ø6x30mm Ø4x40mm Connect the component with No.8 plate using wooden dowel(C), and fix with screw(D) as shown. Ø6x30mm Ø4x40mm Connect No.7 plate with the component using wooden dowel(C), and fix with screw(D) as shown. Use sticker(N) to cover screws. 6/15...
- Page 7 Knock foot peg(O) into the bottom as shown. Ø6x30mm Ø4x40mm Connect No.5 plate with No.3 using wooden dowel(C), and fix with screw(D) as shown. Use sticker(N) to cover screws. 7/15...
- Page 8 Ø6x30mm Ø4x40mm Connect No.2 plate with No.5 using wooden dowel(C), and fix with screw(D) as shown. Use sticker(N) to cover screws. Ø6x35mm Insert quickfit screw(A) into corresponding holes in No.6 plate with a screwdriver as shown. 8/15...
- Page 9 Ø6x30mm Ø4x40mm Attach No.6 to No.2 and No.3 plate using wooden dowel(C) and fix with screw(D) as shown. Ø6x30mm Ø4x40mm Cover No.1 to No.2 and No.3 plate using wooden dowel(C) and fix with screw(D) as shown. Use sticker(N) to cover screws.
- Page 10 Ø15x10mm Ø6x30mm Connect the two assembled components with wooden dowel(C) and turn cam lock(B) clockwise to tighten as shown. Recommend more than 2 people to assemble! 10/15...
- Page 11 Mx24 Ø3x12mm Fix No.11 with No.12 plate together using iron sheet(L) with nail(M) as shown. Fix part(K-1) to No.11 plate with washer(K-2) and screw (K-3) Fix No.11 and No.12 back plate with screw(I) and nail(M) as shown. Insert part(H) into No.2, No.3, No.7 and No.8 plates.
- Page 12 Ø4x14mm Fix hinge(F) to No.13 plate with screw(E) as shown. Fix handle(G-2) with screw(G-1). Ø4x14mm Fix hinge(F) to No.14 plate with screw(E) as shown. Fix handle(G-2) with screw(G-1). 12/15...
- Page 13 Ex16 Ø4x14mm Attach No.13 plate to No.7; No.14 plate to No.2 by fixing hinge with screw(E) as shown. 13/15...
- Page 14 If there is misalignment after you install, just adjust the screw to the best condition. 14/15...
- Page 15 WALL WALL WALL drilling hole Ø6x30mm WALL 15/15...
