- Page 1 wardrobe 1/20 Version:06/07/2022...
- Page 2 IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
- Page 3 Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size Ax37 Bx37 Cx46 Dx21 Ø6x30mm Ø4x35mm Ø6x35mm Ø15x10mm Ex21 Fx18 Hx11 Ø3x12mm Ø3x12mm Ø3.5x12mm Ø4x14mm Nx10 Rx24...
- Page 4 CLx2 CRx2 DLx2 DRx2 300mm 300mm 300mm 300mm 4/20...
- Page 5 5/20...
- Page 6 CLx1 CRx1 Ø3x12mm 300mm Ø3.5x12mm 300mm Attention, second hole Attention, First hole Ø15x10mm Ø6x30mm Ø6x35mm Ø4x35mm Please pay attention to the holes where the accessories are inserted Do not use an electric screwdriver, do not use force during the rotation of the accessories, otherwise it may cause the board to crack Turn...
- Page 7 Cx14 Ø6x30mm Please pay attention to the holes where the accessories are inserted Ax12 CLx1 CRx1 300mm 300mm Ø6x35mm Ø3x12mm Insert quickfit screw A to corresponding pre-drilled holes. Fix runner CL&CR to panel 4,5 using screw E. Do not use an electric screwdriver, do not use force during the rotation of the accessories, otherwise it may cause the board to crack 7/20...
- Page 8 Ø15x10mm Attach panel 4 to the assembled components , and turn cam locks B clockwise to tighten, as shown. Ø15x10mm Attach panel 6 to the aseembled components , and turn cam locks B clockwise to tighten, as shown. 8/20...
- Page 9 Ø6x30mm Ø6x35mm Ø15x10mm First insert quickfit screw A to panel 2&3. Then attach panel 7&13 to the 2 as shown, and turn cam locks B clockwise to tighten, as shown. Turn 9/20...
- Page 10 Ø3.5x12mm Ø6x30mm Ø4x35mm Attach panel 1 using wooden dowel C and screw D. Please pay attention to the holes where the accessories are inserted. Fx18 Ø3x12mm 10/20...
- Page 11 Ax10 Ø6x35mm Ø15x10mm Ø4x35mm Attach panel 1 using screw D, and turn cam locks B clockwise to tighten, as shown. Please pay attention to the holes where the accessories are inserted. Please pay attention to the holes where the accessories are inserted Turn Ø15x10mm Ø6x30mm...
- Page 12 Rx12 Ø3.5x14mm Fix hinges J to panel 19, then attach the door using screw R. Turn J Rx4 12/20...
- Page 13 Rx12 Ø3.5x14mm Turn Ø6x35mm Do not use an electric screwdriver, do not use force during the rotation of the accessories, otherwise it may cause the board to crack 13/20...
- Page 14 Ø15x10mm Ø4x35mm Insert panel 25 to the available slotS in panel 24&23, and turn cam locks B clockwise to tighten, as shown. DLx1 DRx1 Ø3x12mm 300mm 300mm 14/20...
- Page 15 Ø6x35mm Do not use an electric screwdriver, do not use force during the rotation of the accessories, otherwise it may cause the board to crack Ø15x10mm Ø4x35mm Insert panel 25 to the available slotS in panel 24&23, and turn cam locks B clockwise to tighten, as shown. 15/20...
- Page 16 DLx1 DRx1 Ø3x12mm 300mm 300mm 16/20...
- Page 17 17/20...
- Page 18 Nx10 Ø4x14mm Ø3x16mm 18/20...
- Page 19 Ø4x35mm WALL 19/20...
- Page 20 If there is misalignment after you install, adjust the screw to the best condition. 20/20...
-
Page 21: Warranty Claims
WARRANTY WARRANTY CLAIMS •There is a 30-day warranty for broken furniture or any other problems that do not work properly. The warranty will start from the date of purchase which must be verified by proof of purchase. •Before making a claim, we may be able to answer your query, simply call us. Please leave your purchase order number, along with some details of the problem, if you want a replacement part. - Page 22 RETURNS CHANGED YOUR MIND AND NEED TO RETURN YOU ITEM? PLEASE FOLLOW THE BELOW INSTRUCTIONS: •If you have purchased and have simply changed your mind, follow the retailer’s instructions for returns. DEFECTIVE ITEMS •If your item is defective in any way, i.e. it doesn’t work but you can’t identify why, in the first instance, please call us.
