DEMO MANUAL DC2373A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 2 C2, C12
2 2 C4, C8
3 1 C5
4 1 C6
5 1 C7
6 1 C11
7 1 L1
8 2 R1, R4
9 1 R2
10 1 R3
11 1 R5
12 1 R7
13 1 U1
Additional Demo Board Circuit Components
1 1 C1
2 2 C3, C10
3 1 C9
4 1 C13
5 1 C14
6 1 FB1
7 1 L2
8 0 R6 (OPT)
Hardware: For Demo Board Only
1 9 E2 TO E10
2 1 E1 (OPT)
3 1 JP1
4 1 XJP1
5 4 MH1 TO MH4
6
PART DESCRIPTION
CAP , X7R, 0.1µF, 100V, 10%, 0603
CAP , X7R, 0.1µF, 16V, 10%, 0603
CAP , C0G, 10pF, 25V, 5%, 0603
CAP , X5R, 100µF, 10V, 20%, 1210
CAP , X7R, 1µF, 25V, 10%, 0603
CAP , X7S, 4.7µF, 100V, 10%, 1206
IND, 2.2µH
RES, CHIP , 1M, 1/10W, 1%, 0603
RES, CHIP , 18.2k, 1/10W, 1%, 0603
RES, CHIP , 100k, 1/10W, 1%, 0603
RES, CHIP , 191k, 1/10W, 1%, 0603
RES, CHIP , 0, 1/10W, 1%, 0604
IC, REGULATOR, 20-QFN, UDC
CAP , ALUM 22µF, 100V
CAP , X7S, 4.7µF, 100V, 10%, 1210
CAP , X7R, 1µF, 25V, 10%, 0603
CAP , X7R, 10µF, 10V, 10%, 0805
CAP , X7R, 0.1µF, 100V, 10%, 0603
FERRITE BEAD, 0805
IND, 0.22µH
RES, 0603
TESTPOINT, TURRET, 0.094"
TESTPOINT, TURRET, 0.094"
DOUBLE ROW HEADER 2 x 4 0.079"
SHUNT, 0.079" CENTER
STAND-OFF , NYLON 0.50" TALL
MANUFACTURER/PART NUMBER
MURATA, GRM188R72A104KA35D
MURATA, GRM188R71C104KA01D
AVX, 06033A100CAT2A
MURATA, GRM32ER61A107ME20L
MURATA, GRM188R71E105KA12D
AVX, 12061Z475KAT2A
VISHAY, IHLP2525CZER2R2M01
VISHAY, CRCW06031M00FKEA
VISHAY, CRCW060318K2FKEA
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW0603191KFKEA
VISHAY, CRCW06030000Z0EA
LINEAR TECH,LT8641EUDC#PBF
SUN ELECT, 100CE22BS
TDK, C3225X7S2A475K200AB
MURATA, GRM188R71E105KA12D
MURATA, GRM21BR71A106KE51L
MURATA, GRM188R72A104KA35D
TDK, MPZ2012S300A
VISHAY, IHLP1212BZERR22M11
MILL-MAX, 2501-2-00-80-00-00-07-0
SULLINS NRPN042PAEN-RC
SAMTEC 2SN-BK-G
KEYSTONE, 8833 (SNAP ON)
