Modine Manufacturing ECO CDD Series Technical Manual page 41

CDD4 - Ø450 mm fan diameter unit 6 rows
Model CDD "ED"
Ø450
Rows
Total power W
CDD4 - Ø450 mm fan diameter unit 8 rows
Model CDD "ED"
Ø450
Rows
Total power W
41A04 42A04 43A04
41A07 42A07 43A07
41A10 42A10 43A10
6 6 6
5040 10200 15000
41B04 42B04 43B04
41B07 42B07 43B07
41B10 42B10 43B10
8 8 8
5040 10200 15000
RBA - High power electric heater in coil
RSA - High power electric heater on inner drip tray
STANDARD
RBA - High power electric heater in coil
RBB - Low power electric heater in coil
RSA - High power electric heater on inner drip tray
STANDARD
to be set
to be set
