Plugging the board into the slot

♦ Insert the board vertically into the chosen slot.
♦ Fasten the board to the rear of the PC housing with the screw which
was fixed on the back cover.

Fig. 6-4: Fastening the board at the back cover

♦ Tighten all the loosen screws.
6.4

Closing the PC

♦ Close your PC as described in the manual of the PC manufacturer.

Fig. 6-3: Inserting the board

Installation of the board
21
