Installation of the board

6 INSTALLATION OF THE BOARD
i
IMPORTANT!
Do observe the safety precautions (yellow leaflet)!
6.1

Opening the PC

♦ Switch off your PC and all the units connected to the PC
♦ Pull the PC mains plug from the socket.
♦ Open your PC as described in the manual of the PC manufacturer.
6.2

Selecting a free slot

Insert the board in a free ISA XT/AT slot.
Remove the back cover of the selected slot according to the instructions of
the PC manufacturer. Keep the back cover. You will need it if you remove
the board
Discharge yourself from electrostatic charges.
Take the board out of its protective blister pack.
20

Fig. 6-1: PCI-5V slot (32-bit)

Fig. 6-2: Opening the blister pack

PA 1500
