Emergency Reserve Manifold
Figure 6 - Cylinder header extension fitting de-
tails (upgrade to 2 x 2)
3/8" BSP plug and
bonded seal
Wall mounting
holes x 4
Header Extension
Figure 7 - Typical cylinder header extension
layout details (upgrade to 2 x 2), extension kits
from table 2.
3/8" x 5/8 BSP
C/W seals
11
2005715.05
