LCD Monitor Wall Mounting

This LCD Monitor complies with the VESA standard for wall mounting. Follow
the steps below for wall mounting of your LCD Monitor:
Step 1
a. Press the switch (tab) located at
the back near the base of the
monitor.
b. While pressing the switch (tab),
push the monitor from the front.
Step 2
Fold down the display panel in the
direction indicated by the arrow in the
illustration.
Step 3
When the display panel is parallel or
even with the base, the monitor is
ready for wall mounting.
Appendix C
17
