Summary of Contents for Microtek JTX V9s
-
Page 2: Fcc Compliance Statement
FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. this device may not cause harmful interference, and 2. this device must accept any interference received, including interfer- ence that may cause undesired operation. -
Page 3: Radio Frequency Interference Statement
CE mark for Class B ITE EN61000-3-2/1995; EN61000-3-3/1995, EN55024/1998, EN60950/1992+A1+A2+A3+A4+A11) Radio Frequency Interference Statement Warning: This is a Class B product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. -
Page 4: Table Of Contents
Your New LCD Monitor Unpacking Identifying Components Adjusting the Viewing Angle Connecting AC Power, Video and Audio Cable Power Management System The LCD Monitor’s Display Controls Adjusting the Monitor’s Display LCD Monitor Specifications Supported Timing LCD Monitor Wall Mounting Troubleshooting... -
Page 6: Your New Lcd Monitor
LCD Monitor’s small footprint gives you more room in your work- space for other peripherals. Lightweight and compact, the LCD Monitor is the perfect solution for users on the go. You can use the LCD Monitor for everything from making business presentations to playing computer games. - Page 7 If you find any item to be missing or appear to be damaged, contact your dealer immediately. Do not throw away the packing material or shipping carton in case you need to ship or store the LCD Monitor in the future.
-
Page 8: Identifying Components
This LED indicator stays lit when the power is on and blinks when the LCD monitor is in power-saving mode. 2. Monitor Stand 3. LCD Screen The LCD monitor screen is a 19-inch TFT 1280 x 1024 screen. 4. LCD Monitor Control Panel Refer to Chapter 2 for more details. - Page 9 B. "Hot Keys" for Quick Adjustment of Monitor Settings Figure 1-2: "Hot Keys" 1. Auto-adjust "hot key": Press button 2 to apply the monitor setting auto- matically. A small “AUTO ADJUST” OSD is also displayed. 2. Adjust-volume "hot key": Press button 3 to allow you to adjust the audio...
- Page 10 3. Contrast-adjust "hot key": Press button 4 to allow you to adjust the contrast of the display directly. ** To close the small OSD windows, press the power button (button 5).
-
Page 11: Adjusting The Viewing Angle
1. DC Power Jack for AC adapter 2. Audio Line-in 3. VGA Cable Connector 4. Digital Cable Connect Adjusting the Viewing Angle The LCD Monitor’s vertical angle setting range is from -5° to 20°. Figure 1-3: LCD Monitor’s Rear Ports Figure 1-4: Angle Settings... -
Page 12: Connecting Ac Power, Video And Audio Cable
When the LCD Monitor is in power-saving mode or detects an incorrect timing, the Monitor screen will go blank and the power LED indicator will start to blink. -
Page 13: The Lcd Monitor's Display Controls
This button lets you go through the suboptions within a par- ticular OSD control (ex. Auto Adjust, H-Position, etc. under "Monitor Control" in the OSD). Once you are within a subop- tion (ex. in H-Position), you can also use this button to increase values. -
Page 14: Power Switch
5. Power Switch This button lets you turn power for the LCD monitor ON or OFF. This is also a "hot key" to close the OSD menu while it is on display. Adjusting the Monitor’s Display OSD Main Menu To access the OSD main menu, press the OSD Menu button. Use the Function Select buttons to scroll through the various OSD controls. - Page 15 The OSD-Control option lets you adjust the position of the OSD OSD-V- POSITION: Changes the position of the OSD on a The Monitor-Control option allows you to adjust the LCD monitor’s display characteristics. AUTO-ADJUST : Applies automatic monitor settings for optimal viewing.
- Page 16 BRIGHTNESS: Adjusts the level of light or brightness on the LCD monitor’s display screen. Brightness should be adjusted COLOR: Selects the LCD monitor’s color display. The available options are 9300, 6500 and User. The 9300 and 6500 options let you set the Color Temperature to CIE coordinates 9300° or 6500°...
- Page 17 AUDIO-VOLUME: Increases or decreases the volume of the LCD monitor’s sound system. INFORMATION: Indicates the display mode and firmware version of the LCD Monitor. EXIT: Exits the Misc-Control submenu. OSD Exit Option The OSD Exit option lets you close the OSD program. Take note that the OSD menu will close automatically if left inactive for a few seconds.
-
Page 18: Digital Mode
B. Digital mode: Pressing the OSD Menu button causes the following screen to appear (an example): Monitor-Control Option The Monitor-Control option allows you to adjust the LCD moni- PORT-SELECT: Changes input between VGA port and DVI digital port. OSD-Control Option... - Page 19 Graphic-Control Option The Graphic-Control option lets you make adjustments that effect the contrast, brightness and color of the LCD monitor’s display. CONTRAST: Adjusts the difference between the lightest and BRIGHTNESS: Adjusts the level of light or brightness on the LCD monitor’s display screen. Brightness should be adjusted RESET: Resets the Contrast, Brightness and Color parameters.
- Page 20 OSD Exit Option The OSD Exit option lets you close or exit the OSD program. Take note that the OSD menu will close automatically if left inactive for a few seconds.
- Page 21 Note: NO VIDEO When the monitor is ON and there is no Video signal received, the “NO VIDEO” message will be dis- played. Signal out of monitor’s supported range When the frequency range is out of the monitor’s specifications, or...
-
Page 22: Lcd Monitor Specifications
LCD Monitor Specifications LCD Panel Control Func- tions Power On-Screen Main Menu Display (OSD) Display Area (mm) Display Colors Video Interface Analog port: VGA Compatible Analog RGB (15-pin D-Sub) Separate Sync. /Composite / Sync On Green Digital port: DDWG compliant Single Link Tmds Digital... - Page 23 Input Detection Scanning Fre- quency H/V, Hz (Analog mode) Scanning Fre- quency H/V, Hz (Digital mode) Power Manage- ment Power Consump- tion (ON/OFF, W) Dimensions WxHxD Net Weight (Approx.) Power Supply Options Environment Audio (Two 1 Watt speakers with amplifier) Regulatory AUTO-detection and OSD item for manual selection Meets VESA DPMS...
-
Page 24: Supported Timing
Supported Timing Item Standards Resolution 640x400 PC98 640x400 PC98 MAC 13” 640x480 mode MAC 16” 832x624 mode MAC 17” 1024x768 mode 640x350 640x400 640x480 VESA 640x480 VESA 640x480 VESA 800x600 SVGA 800x600 VESA 800x600 VESA 800x600 720x400 1024x768 VESA 1024x768 VESA 1024x768 1024x768... - Page 25 *Once a mode is optimized, there is no need to make any further ad- justment as long as the VGA card remains unchanged. *Specifications are subject to change without notice.
-
Page 26: Lcd Monitor Wall Mounting
LCD Monitor Wall Mounting This LCD Monitor complies with the VESA standard for wall mounting. Fol- low the steps below for wall mounting of your LCD Monitor: Step 1 a. Press the switch (tab) located at the back near the base of the moni- tor. -
Page 27: Troubleshooting
VGA card is selected. This LCD Monitor supports multiple VGA modes. Refer to Appendix B for a listing of the factory preset modes supported by this LCD Monitor. PROBLEM: Display is unclear and unstable To stabilize and clarify your display, follow this procedure in this order: It’s best to adjust the display on a screen displaying of vertical lines. - Page 28 Refer to Appendix B for information on timing. Turn off the LCD Monitor and then turn it back on again. Press the upper Function Control button (refer to Chapter 2) once and then press either the upper or lower Adjustment Control button several times.
