Supported Timing - Microtek JTX V7s User Manual

Supported Timing

Item Standards
1 NEC
PC98
2 NEC
PC98
3 MAC 13"
mode
4 MAC 16"
mode
5 MAC 17"
mode
6 VGA
7 VGA
8 VGA
9 VESA
10 VESA
11 VESA
12 SVGA
13 VESA
14 VESA
15 VGA
16 XGA
17 VESA
18 VESA
19
20 VESA
21
22 VESA
23 VESA
24 VESA
25 VESA
26 SUN
27 SUN
*A=Analog Mode; G=Sync On Green Mode
Appendix B
Dot
Clock
Resolution
(MHz)
640x400 25.20
640x400 21.05
640x480 30.24
832x624 57.28
1024x768 80.00
640x350 25.18
640x400 25.18
640x480 25.18
640x480 31.50
640x480 31.50
800x600 36.00
800x600 40.00
800x600 50.00
800x600 49.50
720x400 28.32
1024x768 65.00
1024x768 75.00
1024x768 78.75
1024x768 71.64
1152x864 108.00
1152x870 100
1280x960 108.0
1280x1024 108.0
1280x1024 127.0
1280x1024 135.0
1024x768 64.13
1024x768 74.25
Vertical Horizontal
Scanning Scanning
Frequency Frequency
(Hz) (kHz)
70.15 31.50
56.42 24.83
66.67 35.00
74.55 49.73
75.02 60.24
70.09 31.47
70.09 31.47
59.94 31.47
72.81 37.86
75.00 37.50
56.25 35.16
60.32 37.88
72.19 48.08
75.00 46.88
70.09 31.47
60.00 48.36
70.07 56.48
75.03 60.02
66.13 53.96
75.00 67.50
75.06 68.68
60.0 60.0
60.02 63.98
69.85 74.88
75.03 79.98
59.98 48.29
70.04 56.59
15
Sync Polarity Operat-
or composite ing Mode
sync (H/V)
-/- A/G
-/- A/G
-/- A/G
-/- A/G
-/- A/G
+/- A/G
-/+ A/G
-/- A/G
-/- A/G
-/- A/G
+/+ A/G
+/+ A/G
+/+ A/G
+/+ A/G
-/+ A/G
-/- A/G
-/- A/G
+/+ A/G
+/+ A/G
+/+ A/G
-/- A/G
+/+ A/G
+/+ A/G
+/+ A/G
+/+ A/G
H+V A
H+V A
