SECTION 1
MODEL
IC-F2000
IC-F2000S
IC-F2000T
IC-F2000
IC-F2000S
IC-F2000T
IC-F2000
IC-F2000S
IC-F2000T
IC-F2000
IC-F2000S
IC-F2000T
IC-F2000
IC-F2000S
IC-F2000T
IC-F2000
IC-F2000S
IC-F2000T
■
GENERAL
• Frequency coverage:
• Number of conventional channels:
• Type of emission:
• Antenna impedance:
• Operating temperature range:
• Power supply voltage:
• Current drain (approximate):
• Dimensions (projections not included):
• Weight (approximate):

SPECIFICATIONS

FREQUENCY
VERSION
COVERAGE (MHz)
EUR-09
UK-09
EXP-09
EUR-09
UK-09
EXP-09
EUR-09
UK-09
EXP-09
EXP-10
EXP-11
AUS-09
AUS-10
UAS-07
USA-08
See the table shown above.
16 channels (Non-display type)
128 channels (4-key and 10-key types)
Wide 16K0F3E (25.0 kHz)
Middle 14K0F3E (20.0 kHz)
Narrow 11K50F3E (12.5 kHz)
8K50F3E (12.5 kHz)
50 Ω (nominal)
−25ºC~+55ºC
−30ºC~+60ºC (−22ºF~+140ºF)
Specified Icom's battery packs only, 7.5 V DC (negative ground)
Receiving 80 mA (stand-by)
500 mA (at maximum audio, with the internal speaker)
Transmitting 1300 mA (at 4 W)
With BP-278 52.2 (W)×111.8 (H)×22.3 (D) mm, 2.1 (W)×4.4 (H)×0.9 (D) inches
With BP-279 52.2 (W)×111.8 (H)×24.5 (D) mm, 2.1 (W)×4.4 (H)×1.0 (D) inches
With BP-280 52.2 (W)×111.8 (H)×30.3 (D) mm, 2.1 (W)×4.4 (H)×1.2 (D) inches
With BP-278 230 g, 8.1 oz
With BP-279 240 g, 8.5 oz
With BP-280 270 g, 9.5 oz
CORRESPONDING
MEASUREMENT STANDARD
EN 300 086, EN 300 296
EN 300 086, EN 300 296
400~470
EN 300 086, EN 300 296
450~520 TIA-603 equivalent
400~470
AS/NZS 4295
450~520
400~470 TIA-603, RSS-119
450~512
1-1
RSS-119
RSS-119
RSS-119
TIA-603
(EN 300 086, EN 300 296, AZ/NZS 4295)
(EN 300 086, EN 300 296)
(TIA-603, RSS-119)
(EN 300 086, EN 300 296, AZ/NZS 4295)
(EN 300 086, EN 300 296)
(TIA-603, RSS-119, AZ/NZS 4295)
