Icom IC-F2000 Service Manual page 21

4-3 TRANSMIT ADJUSTMENTS (CONTINUED)
1) Select an adjustment item using [↑]/[↓]/[←]/[→] on the PC's keyboard.
2) Set or modify the adjustment value as specified using [Space]/[Back Space] on the PC's keyboard.
TRANSCEIVER'S
ADJUSTMENT
CTCSS/DTCS 1
DEVIATION
- Preparation -
- Adjustment - 2
Narrow
(Band low)
3 • Transmitting
4
(Band center) 5 • Transmitting
6
(Band high) 7 • Transmitting
8
Wide* 3 9 • CH No.: 22
(Band low) • Transmitting
Middle* 4 10 • CH No.: 25
(Band low) • Transmitting
CTCSS 1 • CH No.: 19
DEVIATION • Transmitting
- Verification -
Narrow
(Band low)
(Band center) 2 • CH No.: 20
• Transmitting
(Band high) 3 • CH No.: 21
• Transmitting
Wide* 3 4 • CH No.: 22
(Band low) • Transmitting
(Band center) 5 • CH No.: 23
• Transmitting
(Band high) 6 • CH No.: 24
• Transmitting
Middle* 4 7 • CH No.: 25
(Band low) • Transmitting
(Band center) 8 • CH No.: 26
• Transmitting
(Band high) 9 • CH No.: 27
• Transmitting
No adjustment or verification is necessary for [USA].
* 3
No adjustment or verification is necessary for [USA] and [AUS].
* 4
CONDITION
– • Set the preset memory channel
numbers on the adjust utility
window.
• No audio signal is applied to [MIC].
–
–
–
–
• Connect the modulation analyzer
to the antenna connector through
the attenuator, and set it to:
HPF:
LPF:
De-emphasis:
Detector:
• No audio signal is applied to [MIC].
OPERATION
OFF
15 kHz
OFF
(P−P)/2
4-11
ADJUSTMENT
VALUE
ITEM
[CH No. FL]
[CH No. FC]
[CH No. FH]
Push [ENTER]
[TONE Start]
(Enters the
Adjustment mode)
[TONE FL] ±0.35 kHz
(±0.05 kHz)
Push [ENTER]
[TONE Start]
(Saves the value)
[TONE FC] ±0.35 kHz
(±0.05 kHz)
Push [ENTER]
[TONE Start]
(Saves the value)
[TONE FH] ±0.35 kHz
(±0.05 kHz)
Push [ENTER]
[TONE Start]
(Saves the value)
[TONE (Wide)] ±0.70 kHz
(±0.05 kHz)
[TONE (Mid)] ±0.55 kHz
(±0.05 kHz)
– ±0.25~±0.50 kHz
±0.50~±0.90 kHz
±0.40~±0.75 kHz
Continued on the next page...
