4-3 TRANSMIT ADJUSTMENTS (CONTINUED)
1) Select an adjustment item using [↑]/[↓]/[←]/[→] on the PC's keyboard.
2) Set or modify the adjustment value as specified using [Space]/[Back Space] on the PC's keyboard.
TRANSCEIVER'S
ADJUSTMENT
FM DEVIATION 1 • CH No.: 1
- Verification - • Transmitting
Narrow
(Band low)
(Band center) 2 • CH No.: 2
• Transmitting
(Band high) 3 • CH No.: 3
• Transmitting
Wide* 3 4 • CH No.: 10
(Band low) • Transmitting
(Band center) 5 • CH No.: 11
• Transmitting
(Band high) 6 • CH No.: 12
• Transmitting
4
Middle* 7 • CH No.: 13
(Band low) • Transmitting
(Band center) 8 • CH No.: 14
• Transmitting
(Band high) 9 • CH No.: 15
• Transmitting
MODULATION 1 • CH No.: 1
SENSITIVITY • Transmitting
- Verification -
Narrow
(Band low)
(Band center) 2 • CH No.: 2
• Transmitting
(Band high) 3 • CH No.: 3
• Transmitting
Wide* 3 4 • CH No.: 10
(Band low) • Transmitting
(Band center) 5 • CH No.: 11
• Transmitting
(Band high) 6 • CH No.: 12
• Transmitting
Middle* 4 7 • CH No.: 13
(Band low) • Transmitting
(Band center) 8 • CH No.: 14
• Transmitting
(Band high) 9 • CH No.: 15
• Transmitting
No verification is necessary for [USA].
* 3
No verification is necessary for [USA] and [AUS].
* 4
CONDITION
• Connect the audio generator and
AC millivoltmeter to [MIC] through
the JIG cable 1, and set it to:
Frequency: 1 kHz
Waveform: Sine wave
Level:
• Connect the modulation analyzer
to the antenna connector through
the attenuator, and set it to:
HPF:
LPF:
De-emphasis:
Detector:
• Connect the audio generator and
AC millivoltmeter to [MIC] through
the JIG cable 1, and set it to:
Frequency: 1 kHz
Waveform: Sine wave
Level:
OPERATION
150 mV rms
OFF
20 kHz
OFF
(P−P)/2
15.0 mV rms
4-10
ADJUSTMENT
VALUE
ITEM
– ±1.8~±2.45 kHz
±3.6~±4.9 kHz
±2.8~±3.92 kHz
– ±1.10~±1.90 kHz
±2.20~±3.80 kHz
±1.75~±3.05 kHz
Continued on the next page...
