4-3 TRANSMIT ADJUSTMENTS (CONTINUED)
1) Select an adjustment item using [↑]/[↓]/[←]/[→] on the PC's keyboard.
2) Set or modify the adjustment value as specified using [Space]/[Back Space] on the PC's keyboard.
TRANSCEIVER'S
ADJUSTMENT
DTCS 1 • CH No.: 28
DEVIATION • Transmitting
- Verification -
Narrow
(Band low)
(Band center) 2 • CH No.: 29
• Transmitting
(Band high) 3 • CH No.: 30
• Transmitting
3
Wide* 4 • CH No.: 31
(Band low) • Transmitting
(Band center) 5 • CH No.: 32
• Transmitting
(Band high) 6 • CH No.: 33
• Transmitting
4
Middle* 7 • CH No.: 34
(Band low) • Transmitting
(Band center) 8 • CH No.: 35
• Transmitting
(Band high) 9 • CH No.: 36
• Transmitting
5 TONE, 1 • CH No.: 1
2 TONE, DTMF • Transmitting*
DEVIATION
- Verification -
Narrow
(Band low)
(Band center) 2 • CH No.: 2
• Transmitting*
(Band high) 3 • CH No.: 3
• Transmitting*
Wide* 3 4 • CH No.: 10
(Band low) • Transmitting*
(Band center) 5 • CH No.: 11
• Transmitting*
(Band high) 6 • CH No.: 12
• Transmitting*
Middle* 4 7 • CH No.: 13
(Band low) • Transmitting*
(Band center) 8 • CH No.: 14
• Transmitting*
(Band high) 9 • CH No.: 15
• Transmitting*
No verification is necessary for [USA].
* 3
No verification is necessary for [USA] and [AUS].
4
*
* 5 When the embedded programming file (described in page 4-4) is used for the adjustment, DTMF code transmission can be
made by pushing [Emer] twice.
CONDITION
• No audio signal is applied to [MIC].
• Connect the modulation analyzer
5 to the antenna connector through
the attenuator, and set it to:
HPF:
LPF:
De-emphasis:
Detector:
• No audio signal is applied to [MIC].
5
5
5
5
5
5
5
5
OPERATION
OFF
15 kHz
OFF
(P−P)/2
4-12
ADJUSTMENT
VALUE
ITEM
– ±0.25~±0.50 kHz
±0.50~±0.90 kHz
±0.40~±0.75 kHz
– ±1.06~±2.12 kHz
±2.12~±4.23 kHz
±1.70~±3.39 kHz
Continued on the next page...
