Operating the Monitor

A. The LCD Monitor's Control Panel
1. Auto: Automatically fixes, centers and fine-tunes the video
signal to eliminate noise and distortion.
2. OSD Menu/select: Displays the OSD menu and selects a
submenu item.
3. Adjustment button —: Indicates cursor movement, or
decreases the value of a selected OSD setting.
4. Adjustment button +: Indicates cursor movement, or
increases the value of a selected OSD setting.
5.
or OFF .
6. Power LED: Indicates various status levels for the monitor,
such as Green (Normal operation) or Orange (Power
management), depending on the monitor's operating mode.
Figure 2: The Control Panel
Power switch: Turns power for the LCD monitor ON
