J/GE-CF-01

Cable Specifications

The physical characteristics must meet or exceed IEEE 802.3™ specifications.
Fiber Cable
Bit Error Rate:
Single mode fiber (recommended): 9 µm
Multimode fiber (recommended):
Multimode fiber (optional):
J/GE-CF-01(SX)
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
J/GE-CF-01(LX1)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
J/GE-CF-01(LX2)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
J/GE-CF-01(LX6)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
J/GE-CF-01(LX100)
J/GE-CF-01(LX101)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
The fiber optic transmitters on this device meet Class I Laser safety
requirements per IEC-825/CDRH standards and comply with 21
CFR1040.10 and 21CFR1040.11.
Copper Cable
Category 5 -- minimum requirement
Gauge = 24 to 22 AWG;
Attenuation = 22.0 dB /100m @ 100 MHz
• Shielded (STP) or unshielded (UTP) twisted-pair may be used
• All pin pairs (1&2, 3&6, 4&5, 7&8) are active in a gigabit network.
• Use only dedicated wire pairs for the active pins:
(e.g., blue/white & white/blue, orange/white & white/orange, etc.)
• Do not use flat or silver satin wire.
4 24-hour Technical Support: 1-800-260-1312 International: 00-1-952-941-7600
<10-9
62.5/125 µm
100/140, 85/140, 50/125 µm
850 nm multimode
min: -10.0 dBm max: -4.0 dBm
min: -17.0 dBm max: 0.0 dBm
7.0 dB
1310 nm single mode
min: -9.5 dBm max: -3.0 dBm
min: -20.0 dBm max: -3.0 dBm
10.5 dB
1310 nm single mode
min: -5.0 dBm max: -0.0 dBm
min: -20.0 dBm max: -3.0 dBm
15.0 dB
1550 nm single mode
min: -3.0 dBm max: +2.0 dBm
min: -23.0 dBm max: -3.0 dBm
20.0 dB
1310/1550 nm single mode
1550/1310 nm single mode
min: -8.0 dBm max: -3.0 dBm
min: -21.0 dBm max: -3.0 dBm
13.0 dB

Technical Specifications

For use with Transition Networks Model J/GE-CF-01 or equivalent
Standards: IEEE 802.3™ 2000
Data Rate: 1000 Mb/s
Dimensions: (w x d x h) 3.0" x 4.0" x 1.0" (76 mm x 121 mm x 25 mm)
Weight: 6 oz. (181 g) (approximate)
Power Consumption: 3.2 Watts; 260 mA @ 12 VDC
Power Supply 12VDC, 1.25 Amp
(The external power supply provided with this product
is UL listed by the power supply's manufacturer.)
Environment: Tmra*:
Storage Temp:
Humidity:
Altitude:
Warranty: Lifetime
*Manufacturer's rated ambient temperature.
The information in this user's guide is subject to change. For the most up-to-date
information on the J/GE-CF-01 media converter, view the user's guide on-line at:
www.transition.com.
Product is certified by the manufacturer to comply with DHHS Rule 21/CFR,
Subchapter J applicable at the date of manufacture.
CAUTION: Visible and invisible laser radiation when open. Do not stare into
beam or view directly with optical instruments.
CAUTION: Use of controls, adjustments or the performance of procedures other
than those specified herein may result in hazardous radiation exposure.
Optional Accessories (sold separately).
Part Number Description
SPS-1872-SA Optional External Power Supply; 18-72VDC Stand-Alone
Output: 12.6VDC, 1.0 A
SPS-1872-CC Optional External Power Supply; 18-72VDC Piggy-back;
Output: 12.6VDC, 1.0 A
E-MCR-04 12-Slot Media Converter Rack (includes universal internal power
supply) 17 x 15 x 5 in. (432 x 381 x 127 mm)
WMBS Optional Wall Mount Brackets; 3.2 in. (91 mm)
WMBD Optional DIN Rail Mount Bracket; 5.0 in. (127 mm)
WMBD-FS Optional DIN Rail Mount Bracket (flat); 3.1in. (79 mm)
techsupport@transition.com -- Click the "Transition Now" link for a live Web chat.
0 to 50°C (32 to 122°F)
-15 to 65°C (5 to 149°F)
5 to 95%, non condensing
0 to 10,000 feet
