Aeotec MultiSensor 7 Quick Start Manual page 8

24/11/2022, 15:52
Action button press
1x Tap (when factory reset)
1x Tap (when already paired)
Press and hold [1, 2 seconds)
Press and hold [2, 5 seconds)
Press and hold [5, 9 seconds)
Press and hold [9, 15
seconds)
https://manual.zwave.eu/backend/make.php?lang=en&sku=AEOEZWA024&cert=ZC12-20120147
https://manual.zwave.eu/backend/make.php?lang=en&sku=AEOEZWA024&cert=ZC12-20120147
LED Status Function
Solid Yellow Pair Mode
Enters Z-Wave pair mode, flashes white/green 4 times
within 2 seconds upon success.
Solid Purple Sends NIF / Excludes device
if Z-Wave controller is in unpair mode, starts blue LED fade
in/out if unpaired and factory reset successfully.
No LED N/A
Solid Red Quick Wakeup
LED will disappear as soon as you release its button. The
MultiSensor 7 will send a wakeup report to your Z-Wave
Controller to take in any queued z-wave commands waiting
in your controller.
Solid Orange Long Wakeup Mode
LED will remain solid Orange upon release of its button for 5
minutes maximum (or until told to sleep by user or z-wave
controller). This will allow you to easily configure this device
while the sensor is used with battery power assuming your
Z-Wave controller does not queue the command.
Solid Cyan Communication Health Test (Direct gateway
communication - does not test through repeaters).
This will test your MultiSensor 7 direct communication to
your Z-Wave Controller. It will remain Cyan while it is
testing.
Once finished it will become a solid color for 2 seconds
as red, yellow, or green to indicate health:
Red = Bad health, can't communicate at all.
Yellow = Moderate health, could use improvement, some
