Aeotec Indoor Siren 6 Quick Start Manual

Aeotec
Indoor Siren 6
SKU: AEOEZW164
Quickstart
This is a secure Sound Switch for Europe. To run this device please connect it to your mains power supply. 1. Set your Z-Wave Controller into its
Device mode in order to add siren into your Z-Wave system. Refer to the Controller
‘
2. Power on siren via the provided power adapter; its LED will be breathing white light all the time.
3. Click siren Action Button once, it will quickly flash white light for 30 seconds until siren is added into the network. It will become constantly bright white
light after being assigned a NodeID.
4. If your Z-Wave Controller supports S2 encryption, enter the first 5 digits of DSK into your Controller
on Siren s housing.
‘
5. If Adding fails, it will slowly flash white light 3 times and then become breathing white light; repeat steps 1 to 4. Contact us for further support if needed.
6. If Adding succeeds, it will quickly flash white light 3 times and then become off. Now, Siren is a part of your Z-Wave home control system. You can
configure it and its automation via your Z-Wave system; please refer to your software
Note:If Action Button is clicked again during the Learn Mode, the Learn Mode will exit. At the same time, Indicator Light will extinguish immediately, and
then become breathing white light.
Important safety information
Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law. The manufacturer, importer,
distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material. Use this
equipment only for its intended purpose. Follow the disposal instructions. Do not dispose of electronic equipment or batteries in a fire or near open heat sources.
What is Z-Wave?
Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart section.
Z-Wave ensures a reliable communication by reconfirming every message (two-way communication) and
every mains powered node can act as a repeater for other nodes (meshed network) in case the receiver is
not in direct wireless range of the transmitter.
This device and every other certified Z-Wave device can be used together with any other certified Z-
Wave device regardless of brand and origin as long as both are suited for the same frequency range.
If a device supports secure communication it will communicate with other devices secure as long as this
device provides the same or a higher level of security. Otherwise it will automatically turn into a lower level
of security to maintain backward compatibility.
For more information about Z-Wave technology, devices, white papers etc. please refer to www.z-wave.info.
Product Description
- S2 Security.- Not only a siren, but also can be used as a doorbell via setting.- Can be wireless controlled by more Button, up to 3.- Longer Button control
distance, up to 120m.- Built-in multiple tones, up to 30.- Built-in multiple adjustable Light Effect.
Prepare for Installation / Reset
Please read the user manual before installing the product.
In order to include (add) a Z-Wave device to a network it must be in factory default state. Please make sure to reset the device into factory default. You can do
this by performing an Exclusion operation as described below in the manual. Every Z-Wave controller is able to perform this operation however it is recommended
to use the primary controller of the previous network to make sure the very device is excluded properly from this network.
Reset to factory default
This device also allows to be reset without any involvement of a Z-Wave controller. This procedure should only be used when the primary controller is inoperable.
To complete the reset process manually, press and hold the Action Button for at least 20s. The LED indicator will quickly flash white light 3 times and then become
breathing white light, which indicates the reset operation is successful.
Safety Warning for Mains Powered Devices
ATTENTION: only authorized technicians under consideration of the country-specific installation guidelines/norms may do works with mains power. Prior to the
assembly of the product, the voltage network has to be switched off and ensured against re-switching.
manual.zwave.eu/backend/make.php?lang=en&sku=AEOEZW164
s manual if you are unsure of how to perform this step.
‘
s interface if/when requested. The DSK is printed
‘
‘ s user guide for precise instructions.
A dd
‘
1/10
