E-FRL-MC04 IN THE NETWORK
NOTE: AUI cable can be used to connect to the transceiver.
10BASE-Fl Hub
OR
OR
SQE = ON
SQE = OFF
Hub with MII connector
SQE = ON

TECHNICAL SPECIFICATIONS

Standards IEEE 802.3
Case Dimensions 2.8" x 1.75" x 0.75"
Environment Temperature:
Humidity
Altitude
Warranty Lifetime
DECLARATION OF CONFORMITY
Name of Mfg: Transition Networks
6475 City West Parkway, Minneapolis MN 55344 USA
Model: AUI/10BASE-FL Transceiver
Part Number: E-FRL-MC04, E-FRL-MC04(SC),E-FRL-MC04(SM),
E-FRL-MC04(L)
Regulation: EMC Directive 89/336/EEC
Purpose: To declare that the E-FRL-MC04 to which this declaration refers is in
conformity with the following standards.
EMC-CISPR 22: 1985 Class A; EN 55022: 1988 Class A; EN 50082-1:1992;
EN 60950 A4:1997; IEC 801.2, IEC 801.3, and IEC 801.4; IEC 950
I, the undersigned, hereby declare that the equipment specified above conforms to the
above Directive(s) and Standard(s).
Stephen Anderson, Vice-President of Engineering
(71mm x 43mm x 18mm)
0-40°C (32° to 104° F )
10-90%, non condensing
0-10,000 feet
_August 11, 1999_____
Date
