Transition Networks E-FRL-MC03 User Manual

Specifications:
Case size dimensions:
Standard:
Fiber Optic Interface
Fiber Connection:
Fiber Optic Cable Maximum Distance:
Fiber Optic Cable Recommended:
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
AUI (DB-15) Interface
Parameter
Transmit
Transmit threshold voltage level:
Transmit turn on delay:
Transmit steady propagation delay:
Transmit loop back start up delay:
Transmit turn off to data idle:
SQE test delay:
SQE test duration:
Receive
Receive turn on delay:
Receive steady propagation delay:
Differential output voltage (RX(-/+)):
Differential output voltage (col(-/+)):
Differential output rise time (RX(-/+), col(-/+)):
Differential output fall time (RX(-/+), col(-/+)):
Collision
Time for SQE to deact. after collision:
Collision frequency:
Collision pulse duty cycle:
SQE test delay:
Jabber activation delay:
Environment:
WARRANTY:
FCC Regulations:
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his own cost.
Canadian Regulations:
Note: This digital apparatus does not exceed the Class A limits for radio noise for digital apparatus set out on the
radio interference regulations of the Canadian Department of Communications.
Copyright Restrictions
© 1995, 1997 Transition Networks, Inc.
All rights reserved. No part of this work may be reproduced or used in any form or by any means - graphic,
electronic, or mechanical - without written permission from Transition Networks, Inc.
Trademarks:
Ethernet is a registered trademark of the Xerox Corporation, Inc.
TRANSITION Networks is a trademark of TRANSITION Networks, Inc.
3.7" x1.75" x 0.8" (94 mm x 44 mm x 20 mm)
Ethernet IEEE 802.3, 1300 nm
ST type connectors (SMA type available upon request)
5,000 meters- 20,000 meters
9/125 micron single mode fiber
Typical transmit power: -22.5dBm
Best case transmit power: -18.5dBm
Worst case transmit power: -28.5dBm
Best case fiber sensitivity: -35dBm
Worst case fiber sensitivity: -30dBm
10 -9
Bit error rate:
Minimum Typical Maximum
-140mV -170mV -190mV
100ns
15ns 50ns
500ns
400ns 2100ns
0.6 µ sec 1.6 µ sec
0.5 µ sec 1.0 µ sec 1.5 µ sec
350ns
15ns 50ns
(+/-)550mV (+/-)1200
(+/-)550mV (+-)1200
4ns
4ns
450ns 700ns
8.5MHz 11.5MHz
40% 50% 60%
0.6 µ sec 1.6 µ sec
20ms 70ms 150ms
0–50 degrees C, 10–90% humidity, non-condensing,
0–10,000 foot altitude
FIVE YEARS
Single Mode Fiber Optic Transceiver
The Transition Networks Single Mode Fiber Optic Transceiver is used to connect
Ethernet IEEE 802.3 AUI (DB-15) nodes to a fiber optic medium using standard ST type
connectors (SMA available).
The compact size of the transceiver allows a direct connection to most AUI ports on
Ethernet compatible workstations, cards, and multiport repeaters.
LEDs indicate status of all MAU functions: Jabber, Collision, Transmit, Receive, Link,
and Power. An external dip switch turns the SQE heartbeat On and Off. The 1300 nm
Single Mode Fiber Optic Transceiver is fully IEEE 802.3 compliant, allowing network
managers to utilize multiple components from multiple vendors without compatibility
problems.
Status LEDs provide the following information:
Transmit: Flashing or illuminated green LED indicates packet(s) are being transmitted.
Receive: Flashing or illuminated green LED indicates packet(s) are being received.
Link Illuminated green LED indicates the unit is receiving link pulses from a
compliant device.
Power: Illuminated green LED indicates normal operation.
Collision: Flashing or illuminated red LED indicates collisions are occurring.
Jabber: Illuminated red LED indicates the unit is disabled.
7358.I
E-FRL-MC03
USER'S GUIDE
E-FRL-MC03
Ethernet™
Single Mode FL Transceiver
On
SQE
T R A N S I T I O N
Off
n e t w o r k s
Mpls, MN 55344
Transmit
Collision Receive
Jabber Link
Power
Minneapolis, MN 55344 USA
RX
TX
