FAULT ISOLATION and CORRECTION

If the media converter fails, isolate and correct the failure by determining the
answers to the following questions and then taking the indicated action:
Is the Power LED on the media converter illuminated?
1.
NO
• Is the media converter inserted properly into the chassis?
• Is the power cord properly installed in the chassis and at the
external power source?
• Does the external power source provide power?
• Contact Technical Support at (800) 260-1312.
YES
• Proceed to step 2.
2. Is the SDC (Signal Detect/Copper) LED illuminated?
NO
• Check UTP cables for proper connection.
• Contact Technical Support at (800) 260-1312.
YES
• Proceed to step 3.
3. Is the SDF (Signal Detect/Fiber) LED illuminated?
NO
• Check fiber cables for proper connection.
• Verify that TX and RX cables on media converter are connected to
RX and TX ports, respectively, on the other 100BASE-FX device.
• Refer to Tech Tips available at: http://www.transition.com
• Contact Technical Support at (800) 260-1312.
YES
• Contact Technical Support at (800) 260-1312.
8
C/E-100BTX-FX-05

CABLE SPECIFICATIONS

The physical characteristics of the media cable must meet or exceed IEEE 802.3 specifications.

Fiber Cable

Bit error rate:
MULTIMODE
Fiber Optic Cable Recommended:
Optional:
C/E-100BTX-FX-05
C/E-100BTX-FX-05(SC)
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
Typical Maximum Cable Distance*:
C/E-100BTX-FX-05(MT)
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
Typical Maximum Cable Distance*:
SINGLEMODE
Fiber Optic Cable Recommended:
C/E-100BTX-FX-05(SM)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
Typical Cable Distance*:
C/E-100BTX-FX-05(SMLC)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
Typical Cable Distance*:
C/E-100BTX-FX-05(LH)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Minimum Attenuation:
Typical Cable Distance*:
C/E-100BTX-FX-05(XL)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Minimum Attenuation:
Typical Cable Distance*:
C/E-100BTX-FX-05(LW)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Spectral Width
Minimum Attenuation:
Typical Cable Distance*:
*Actual distance dependent upon physical characteristics of network installation.
The fiber optic transmitters meet Class I Laser safety requirements per IEC-
825/CDRH standards and comply with 21 CFR1040.10 and 1040.11.
-9
<10
62.5 / 125 µm multimode fiber
100 / 140 µm multimode fiber
85 / 125 µm multimode fiber
50 / 125 µm multimode fiber
1300 nM
1300 nM
min: -19.0 dBm max: -14.0 dBm
min: -30.0 dBm max: -14.0 dBm
11.0 dB
2 kilometers
1300 nM
min: -19.0 dBm max: -14.0 dBm
min: -33.5 dBm max: -14.0 dBm
15.0 dB
2 kilometers
9 µm singlemode fiber
1300 nM
min: -15.0 dBm max: -8.0 dBm
min: -31.0 dBm max: -8.0 dBm
16.0 dB
20 kilometers
1300 nM
min: -15.2 dBm max: -8.0 dBm
min: -32.5 dBm max: -3.0 dBm
17.3 dB
20 kilometers
1300 nM
min: -8.0 dBm max: -2.0 dBm
min: -34.0 dBm max: -7.0 dBm
8 dB
40 kilometers
1300 nM
min: -5.0 dBm max: 0.0 dBm
min: -34.0 dBm max: -7.0 dBm
7 dB
60 kilometers
1550 nM
min: -5.0 dBm max: 0.0 dBm
min: -34.0 dBm max: -7.0 dBm
0.4 nm FWHM
7 dB
80 kilometers
