Transition Networks CETCT1020-100 User Manual

Slide-in-module media converter
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

Enlarged version
User's Guide
CETCT1020-100
Slide-in-Module Media Converter
• Coax to Twisted-Pair
• 10Base-2 to 10Base-T
The Transition Networks CETCT1020-100
Ethernet media is designed to be installed in a
Transition Networks PointSystem™ chassis and
connects 10Base-T shielded or unshielded
twisted-pair copper cable to 10Base-2 coaxial
copper cable.
The CETCT1020-100 supports up to 30 devices
daisy-chained on one coax segment per twisted-
pair segment.
Part Number
Port One - Twisted-Pair
CETCT1020-100
RJ-45, 10Base-T
100 m (328 ft)*
* Typical maximum cable distance. The actual maximum cable distances are
dependent upon the physical characteristics of the network installation.
Port Two - Coax
BNC, 10Base-2
185 m (607 ft)*
Installation . . . . . . . . . . . . . . . . . .2
Operation . . . . . . . . . . . . . . . . . . .4
Cable Specifications . . . . . . . . . . .5
Troubleshooting . . . . . . . . . . . . . .6
Technical Specifications . . . . . . . .7
Compliance Information . . . . . . . .8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CETCT1020-100 and is the answer not in the manual?

Questions and answers

Related Manuals for Transition Networks CETCT1020-100

Summary of Contents for Transition Networks CETCT1020-100

  • Page 1 Transition Networks PointSystem™ chassis and connects 10Base-T shielded or unshielded twisted-pair copper cable to 10Base-2 coaxial copper cable. The CETCT1020-100 supports up to 30 devices daisy-chained on one coax segment per twisted- pair segment. Part Number Port One - Twisted-Pair...

  • Page 2: Installation

    CETCT1020-100 Installation Installation -- Continued CAUTION: Wear a grounding device and observe electrostatic discharge Install the Coax Cable precautions when setting the switches and when installing the slide-in-module. Locate or build 10Base-2 compliant fiber cable with female, BNC Failure to observe this caution could result in damage to, and subsequent failure connectors installed at both ends.

  • Page 3: Cable Specifications

    Attenuation 11.5 dB/100m @ 5-10 MHz SNMP Maximum cable distance: 100 m See the on-line documentation that comes with Transition Networks Category 5: (recommended) FocalPoint™ software for applicable commands and usage. Gauge 24 to 22 AWG Use SNMP at an attached terminal or at a remote location to monitor the Attenuation 22.0 dB/100m @ 100 MHz...

  • Page 4: Troubleshooting

    Regulation: EMC Directive 89/336/EEC • Check 10Base-2 cables for proper connection. Purpose: To declare that the CETCT1020-100 to which this declaration refers is • Verify that 10Base-2 cable connections on media converter and on in conformity with the following standards.

  • Page 5: Compliance Information

    All registered trademarks and trademarks are the property of their respective owners. Copyright Restrictions © 2001, 2004-2005 Transition Networks. All rights reserved. No part of this work may be reproduced or used in any form or by any means - graphic, electronic, or mechanical - without written permission from Transition Networks.
