CABLE SPECIFICATIONS

The physical characteristics of the media cable must meet or exceed IEEE 802.3 specifications.
Fiber Cable
Bit error rate:
MULTIMODE
Fiber Optic Cable Recommended:
Optional:
C/E-100BTX-FX-04
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Typical Maximum Cable Distance*:
C/E-100BTX-FX-04(SC)
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Typical Maximum Cable Distance*:
C/E-100BTX-FX-04(MT)
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Typical Maximum Cable Distance*:
SINGLEMODE
Fiber Optic Cable Recommended:
C/E-100BTX-FX-04(SM)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Typical Cable Distance*:
C/E-100BTX-FX-04(SMLC)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Typical Cable Distance*:
C/E-100BTX-FX-04(LH)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Minimum Attenuation:
Typical Cable Distance*:
C/E-100BTX-FX-04(XL)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Minimum Attenuation:
Typical Cable Distance*:
C/E-100BTX-FX-04(LW)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Spectral Width
Minimum Attenuation:
Typical Cable Distance*:
*Actual distance dependent upon physical characteristics of network installation.
Category 5 twisted-pair copper wire is required. Either shielded twisted-pair (STP)
or unshielded twisted-pair (UTP) can be used. DO NOT USE FLAT OR SILVER
10-9
62.5 / 125 µm multimode fiber
100 / 140 µm multimode fiber
85 / 125 µm multimode fiber
50 / 125 µm multimode fiber
1300 nM
min: -19.0 dBm
max: -14.0 dBm
min: -30.0 dBm
max: -14.0 dBm
2 kilometers
1300 nM
min: -19.0 dBm
max: -14.0 dBm
min: -30.0 dBm
max: -14.0 dBm
2 kilometers
1300 nM
min: -19.0 dBm
max: -14.0 dBm
min: -33.5 dBm
max: -14.0 dBm
2 kilometers
9 µm singlemode fiber
1300 nM
min: -15.0 dBm
max: -8.0 dBm
min: -32.5 dBm
max: -8.0 dBm
20 kilometers
1300 nM
min: -15.0 dBm
max: -8.0 dBm
min: -32.5 dBm
max: -3.0 dBm
20 kilometers
1300 nM
min: -8.0 dBm
max: 0.0 dBm
min: -34.0 dBm
max: -8.0 dBm
8 dB
40 kilometers
1300 nM
min: -5.0 dBm
max: 0.0 dBm
min: -34.0 dBm
max: -7.0 dBm
7 dB
60 kilometers
1550 nM
min: -5.0 dBm
max: 0.0 dBm
min: -34.0 dBm
max: -7.0 dBm
0.4 nm FWHM
7 dB
80 kilometers
INSTALLATION
Set Switches
Use small flatblade screwdriver or similar device to set recessed switches
according to site installation.
Set the MDI/MDI-X switch to MDI for cable connection between hub
and media converter. Set the MDI/MDI-X switch to MDI-X for cable
connection between media converter and terminal, transceiver or
network interface card (NIC).
Referring to drawing on page 2, set four-position switch according to
network configuration.
Install Slide-In-Module in E-MCC-1600 Chassis
Remove Media Converter Slide-in-Module protective plate from selected
installation slot by removing two (2) screw that secures plate to front of
E-MCC-1600.
Carefully slide Media Converter Slide-in-Module into installation slot,
aligning Media Converter Slide-in-Module with installation guides.
NOTE: Ensure that the Media Converter Slide-in-Module is firmly seated
against backplane.
Secure Slide-in-Module by installing panel fastener screw attached to
Slide-in-Module.
Install Cable
COPPER
NOTE: KEEP TWISTED PAIR RUNS AS SHORT AS POSSIBLE.
Locate or build 802.3 compliant cables with straight through
configuration and male RJ-45 plug connectors.
Connect male RJ-45 plug connector at one end of cable to media
converter RJ-45 jack connector.
Connect male RJ-45 plug connector at other end of cable to DTE
terminal RJ-45 jack connector (setting MDI switch to MDI-X) or to Hub
RJ-45 jack connector (setting MDI switch to MDI).
FIBER
Locate or build 802.3 compliant fiber cable with male two-stranded TX
to RX connectors appropriate to the media converter installed at both
ends.
Connect male TX and RX cable connectors at one end of cable to TX
and RX female connectors, respectively, on media converter.
Connect male TX and RX cable connectors at other end of cable to RX
and TX connectors of 802.3 compliant fiber device.
