Enfora GSM1308 and GSM1318
Quad-Band Spider® SA-G+
User Guide
GSM1308UG001
Revision: 1.06
9/10/2010
www.enfora.com
Arrow.com.
Downloaded from

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Quad-Band Spider SA-G+ GSM1308 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enfora Quad-Band Spider SA-G+ GSM1308

Summary of Contents for Enfora Quad-Band Spider SA-G+ GSM1308

  • Page 1 Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ User Guide GSM1308UG001 Revision: 1.06 9/10/2010 www.enfora.com Arrow.com. Downloaded from...

  • Page 2: Copyright

    New Materials. The user of such New Materials assumes all risk (known or unknown) of such use. Enfora reserves all rights in such New Materials. The user shall have only a revocable and limited license to use such New Materials in connection with the products for which they are intended.

  • Page 3: Warranty Information

    (or to Enfora's authorized distributor).Purchaser shall bear the risk of loss or damage in transit to any product returned by purchaser to Enfora, or any returned product not found to be defective or covered under this warranty, and reshipped...
  • Page 4 (90) days, whichever is longer. If Enfora is unable to repair or replace a defective product covered by this limited warranty, Enfora will provide to purchaser a credit or a refund (at Enfora's option) of the original purchase price (excluding taxes and shipping charges).

  • Page 5: Regulatory Compliance

    GSM1308 and GSM1318 SA-G+ complies with Part 15 emission limits. FCC Part 22 & Part 24 is covered by the Enfora Enabler-IIIG "modular approval" process for a transmitter. This approach, described by FCC Public Notice DA...

  • Page 6: Rf Exposure

    GCF, PTCRB, R&TTE, IMEI and other applicable codes that are in effect at the time of publication. Enfora disclaims all responsibility for any act or omissions, or for breach of law, code or regulation, including local or state codes, performed by a third party.
  • Page 7 Enfora shall not be responsible for installations or transmissions that fall outside of the parameters set forth in this publication. User Guide P a g e VI Revision: 1.06 Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 8: Table Of Contents

    TABLE OF CONTENTS General ..........................1 COPYRIGHT ........................1 Warranty Information ......................2 REGULATORY COMPLIANCE ..................4 FCC ..........................4 RF EXPOSURE......................... 5 R&TTE ........................5 Table of Contents ......................7 Table of Figures ........................ 8 Table of Tables ......................... 8 Introduction ....................
  • Page 9 Configure the SA-G+ to talk to the Enfora Server .......... 19 Verifying Server Connectivity ................. 25 Technical Support ..................27 Appendix A SA-G+ Current Measurements (Typical) ........28 GSM ......................28 GPRS ......................31 TABLE OF FIGURES Figure 1 - Front view of GSM/GPRS SA-G+ modem............3 Figure 2 - Rear view of GSM/GPRS SA-G+ modem.

  • Page 10: Introduction

    GSM/GPRS SA-G+ modem. Please follow the instructions herein closely to avoid damaging the GSM/GPRS SA-G+. The GSM/GPRS SA-G+ modem contains an Enfora Enabler-IIIG OEM module. Detailed information pertaining to the specifications and operation of the module will pertain, in part, to the GSM/GPRS SA-G+ platform.

  • Page 11: Technical Notes

    GSM0000AN018 - USNO NTP Network Time Service TCP PAD GSM0000AN019 - Network Configuration Worksheet GSM0000AN022 - Sending AT Commands over SMS GSM0000AN023 - Configure the Modem to talk to the Enfora Server GSM0000AN026 - Using a Terminal Program to Test PAD GSM0000AN027 - AT$ACTIVE Command Implementation Behavior GSM0000AN029 - Enabler IIIG Network Personalization 1.2.3 TECHNICAL NOTES...

  • Page 12: Sa-G+ Front And Back View

    Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ 1.4 SA-G+ FRONT AND BACK VIEW Figure 1 - Front view of GSM/GPRS SA-G+ modem. Figure 2 - Rear view of GSM/GPRS SA-G+ modem. User Guide P a g e 3 Revision: 1.06 Arrow.com.

  • Page 13: Installation

    Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ 2 Installation 2.1 SUBSCRIBER IDENTITY MODULE (SIM) CARD programmed with subscriber information. The user information consists of an International Mobile Subscriber Identity (IMSI) number, which is registered with the consists of a microprocessor and memory installed on a plastic card. To install the SIM card into the modem, insert the SIM card in the modem as shown below in Figure 3.

  • Page 14: R&Tte

    Vdc. If your unit did not include an optional power supply, or if you wish to configure a separate power interface, the following connector parts are the Enfora recommended parts that can be used to mate with the existing modem power...

  • Page 15: Table 2 8 Pin I/O Connector Interface

    The user can purchase the optional eight (8) pin external I/O connector for the Enfora SA-G+ that can be used to interface with other devices. Enfora can provide an optional cable and connector (Part #CAB1308). The user also has the option of building his/her own cable.

  • Page 16: Table Of Contents

    Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ Figure 4 - Molex Connector and Pins 2.2.1 GPIO1 (INPUT/OUTPUT) 2.2.1.1 GPIO 1 ELECTRICAL SPECIFICATIONS Input VIH: >2.2 V Input VIL: <1 V Output VOH: 3 V Output VOL: 0 Max Source Current: Approximately 350 µA Max Sink Current: 3.7 mA @ 40 V, 0.13 W...

  • Page 17: Table Of Figures

    Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ 2.2.2 GPIO2 (INPUT/OUTPUT) PROGRAMMABLE PULL-UP SYSTEM 2.2.2.1 GPIO 2 ELECTRICAL SPECIFICATIONS Input VIH: >2.2 V Input VIL: <1 V Output VOH: 3 V Output VOL: 0 Max Source Current: Approximately 320 µA Max Sink Current: 3.7 mA @ 40 V, 0.13 W 2.2.2.2 GPIO2 AS PULL-DOWN SYSTEM...

  • Page 18: Connecting The Serial Cable

    Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ 2.3 CONNECTING THE SERIAL CABLE To connect the SA-G+ with a local computing device, connect one end (male end) of the 9-wire RS232 Serial Cable to the SA-G+ port labeled "Serial" and connect the other end to a computer.

  • Page 19: Connecting The Gsm/Gprs Antenna

    Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ 2.4 CONNECTING THE GSM/GPRS ANTENNA The antenna is supplied by the user. The antenna must have a nominal impedance of 50 Ohms. The VSWR must be less than 2.0:1. System antenna gain should be 0-2 dB for optimum performance.

  • Page 20: Led Functions

    Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ 2.5 LED FUNCTIONS The GSM/GPRS SA-G+ modem has one green LED on the front panel. REG: Indicates GSM network registration status. Flashing when attempting to register on a GSM network. Solid when the modem is registered with a GSM network.

  • Page 21: Firmware Upgrade

    3 Firmware Upgrade To see if there is updated firmware for the SA-G+, please visit: http://www.enfora.com > support You will need to obtain a login to the website from Enfora Tech Support in order to download the firmware. following behavior: SIM Installed...

  • Page 22: Configure The Computer And Verify Correct Communications

    Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ 4 Configure the Computer and Verify Correct Communications Note: The following examples use Windows 2000 and HyperTerminal. Any Terminal program should work, using the parameters in Step 1 1. Default Serial Parameters Autobaud (power up message at115200 baud rate)
  • Page 23 Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ a. Select the Device Manager button. Expand the Ports section by selecting the + sign beside Ports. Your window should look like the following: User Guide P a g e 14 Revision: 1.06 Arrow.com.
  • Page 24 Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ b. Plug in the USB-to-Serial converter. The window should change to show the USB-to-Serial converter installed. c. Most devices will show the Com port next to the device name. Record this number. In this case, it is COM12.
  • Page 25 On Windows 2000, click on: Start>Programs>Accessories>Communications>HyperTerminal d. You should see the following screen. e. Enter a name for the Connection. In this example, the Name is Enfora Com1. f. Click OK. g. The next window that will appear is the Connect To window.
  • Page 26 Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ h. Change the Connect Using setting to the Com port that was determined in Step B. i. Click OK. j. The next window is the Port Settings window. User Guide P a g e 17 Revision: 1.06...
  • Page 27 Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ k. Make sure the settings match the example. l. Click OK. m. Now the Main Program Window should appear. User Guide P a g e 18 Revision: 1.06 Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 28: Configure The Sa-G+ To Talk To The Enfora Server

    Type AT<CR>. The SA-G+ should respond with OK. If you do not see the letters AT, send the following command to the SA-G+: ATE1<CR> c. Type ATI<CR>. The SA-G+ should respond with Enfora, Inc. If you get any different response, you are not connected to the Enfora SA-G+.
  • Page 29 Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ 2. Configure the SA-G+ to communicate with the Enfora Test Server. a. The following information will need to be obtained from the SIM provider. Please refer to GSM0000AN019 Network Configuration Worksheet. b. APN c.
  • Page 30 Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ e. Configure the SA-G+ to Access the GPRS network. To inform the SA-G+ of the proper APN, send the following command: AT+CGDCONT=1,”IP”,”apn”<CR> (substitute the letters apn for the supplied apn.) To inform the SA-G+ of the proper username and password, (if necessary) send the following command: AT%CGPCO=1,”username,password”<CR>...
  • Page 31 Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ Verify GPRS activation by sending the following command: AT$NETIP?<CR> If the response is non-zero, then everything is working. Skip to Step 10. User Guide P a g e 22 Revision: 1.06 Arrow.com. Arrow.com.
  • Page 32 $CGEER: requested service option not subscribed (APN is incorrect or SIM has not been enabled for data mode.) $CGEER: user authentication failed (username and/or password is incorrect.) Configure the SA-G+ to access the Enfora Server. Note: To configure the SA-G+ for server interoperability, several things have to be addressed.
  • Page 33 Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ Configure the SA-G+ to talk with a specific server. Set the port number Send the following command: AT$UDPAPI=,1721 Enable periodic messages (wakeup) to be sent to the server every 60 seconds Send the following command: AT$WAKEUP=1,1...

  • Page 34: Verifying Server Connectivity

    Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ 6 Verifying Server Connectivity Note: For the following tests, Java Runtime must be installed on the computer. (To install Java Runtime, please visit the Java website here: http://www.java.com/en/download/manual.jsp) 1. Start Internet Explorer and enter the following URL: http://apitest.enfora.com/udpapp/...
  • Page 35 4. Enter the following command in the command/ data block: ATI 5. Select Write. 6. Verify that you see the following the SA-G+ response with Enfora, Inc. If so, you have successfully configured the SA-G+ to talk with the server.

  • Page 36: Technical Support

    For technical support and customer service dealing with the modem itself, contact the company where you purchased the product. If you purchased the product directly from Enfora, visit the Support and Resources page on the Enfora website: http://www.enfora.com.

  • Page 37: Appendix Asa-G+ Current Measurements (Typical)

    Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ 8 Appendix A SA-G+ Current Measurements (Typical) 8.1 GSM Current, mA Band Sleep Mode Peak GSM850 47.91 140.16 824.98 838.66 37.25 129.82 824.22 841.23 46.29 138.43 827.59 839.94 47.71 139.8 828.11 840.8 37.16 130.77...
  • Page 38 Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ GSM Idle Current, mA Band Sleep Mode DRX Mode Peak GSM850 35.3 37.66 75.36 24.12 27.07 59.39 75.58 29.3 37.71 69.37 76.43 35.7 37.57 75.58 23.91 26.88 59.36 80.5 EDS900 35.69 37.77 75.77 81.35...
  • Page 39 Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ Deep sleep alterations Current, mA Peak GSM850 47.53 139.86 825.57 839.52 36.9 129.43 823.07 837.38 45.78 138.62 828.3 841.66 47.1 139.82 830.03 843.37 36.73 129.8 825.26 839.09 Idle GSM850 35.39 37.49 75.36 75.58 23.71...

  • Page 40: Gprs

    Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ 8.2 GPRS GPRS Current, mA Band Sleep Mode Peak GSM850 43.59 131.91 822.8 836.74 33.53 122.2 826.64 845.72 41.79 130.74 828.15 840.59 43.17 132.1 828.09 840.59 33.27 122.72 828.62 845.72 EDS900 44.26 130.58 800.34...
  • Page 41 Enfora GSM1308 and GSM1318 Quad-Band Spider® SA-G+ GPRS Idle Current, mA Sleep Band Mode Mode Peak GSM850 33.63 38.2 75.79 76.65 24.07 27.78 72.79 35.25 38.23 75.79 76.43 35.7 38.15 75.79 76.43 24.32 27.61 60.03 80.28 EDS900 35.29 38.29 79.43 84.78...
