- Page 1 User Manual: GSM1218PB001MAN Enfora GSM1218 Quad-Band SA-GL User Manual Revision 1.04 Enfora L.P. 661 E. 18 Street Plano Texas 75074 www.enfora.com...
- Page 2 All specifications are subject to change without notice and do not represent a commitment on the part of Enfora L.P. Enfora L.P. will not be responsible for any loss or damages incurred related to the use of information contained in this document.
- Page 3 GSM1218 Quad-Band SA-GL User Manual Enfora L.P. 661 East 18th Street Plano, Texas 75074-5601 www.enfora.com Enfora L.P. Proprietary Information GSM1218PB001MAN GSM1218PB001MAN Version 1.04 – 04/05/06...
- Page 4 Limited Warranty ENFORA L.P. 12-MONTH LIMITED WARRANTY Enfora warrants to the original purchaser of the product that, for a period of one (1) year from the date of product purchase, the product hardware, when used in conjunction with any associated software (including any firmware and applications) supplied by Enfora, will be free from defects in material or workmanship under normal operation.
- Page 5 (iii) caused by use of any software other than any software supplied by Enfora, or by use of the product other than in accordance with its documentation or (iv) the result of electrostatic discharge, electrical surge, fire, flood or similar causes.
- Page 6 Release Date Description of Changes Number 1.00 4/30/04 Initial Release Nomenclature Changes, Mounting 1.01 6/4/04 Clarifications 1.02 6/7/04 Corrected Power Connector PNs Updated warranty and technical support 1.03 02/14/05 information 1.04 04/05/06 Added CE Label information GSM1218PB001MAN Version 1.04 – 04/05/06...
-
Page 7: Table Of Contents
Figure 5: Connecting the Serial Cable to SA-GL...........8 Figure 6: GSM/GPRS SA-GL Connecting the Antenna ........10 Figure 7: Attaching a Headset to the GSM/GPRS SA-GL Module ......10 Figure 8 - Mounting Dimensions .................11 Tables Table 1: GSM Operating Power ................7 GSM1218PB001MAN Version 1.04 – 04/05/06... -
Page 8: Introduction
GSM/GPRS SA-GL modem. Please follow the instructions herein closely to avoid damaging the GSM/GPRS SA-GL. The GSM/GPRS SA-GL modem contains an Enfora Enabler-IIG OEM module. Detailed information pertaining to the specifications and operation of the module will pertain, in part, to the GSM/GPRS SA-GL platform. -
Page 9: System Requirements
• One standard plug for speaker and microphone* *not required for stand alone operation SA-GL Front and Back View Figure 1: Front view of GSM/GPRS SA-GL modem. Figure 2: Rear view of GSM/GPRS SA-GL modem. GSM1218PB001MAN Version 1.04 – 04/05/06... -
Page 10: Regulatory Compliance
The modem was tested and certified to meet FCC Parts 15 in a stand-alone configuration, which demonstrated that the GSM1218 SA-GL complies with Part 15 emission limits. FCC Part 22 & Part 24 is covered by the Enfora Enabler-IIG "modular approval" process for a transmitter. This approach, described by FCC... - Page 11 GSM1218 Quad-Band SA-GL User Manual Enfora shall not be liable for consequential or incidental damages, injury to any person or property, anticipated or lost profits, loss of time, or other losses incurred by Customer or any third party in connection with the installation of the Products or Customer's failure to comply with the information and instructions contained herein.
-
Page 12: Installation
GSM service provider and must be provisioned by the operator for data and/or voice. Always take care to protect the SIM: the GSM terminal will not operate without the SIM installed. Figure 3: Inserting a SIM Card in a GSM/GPRS SA-GL Module GSM1218PB001MAN Version 1.04 – 04/05/06... -
Page 13: Connecting The Power Supply
Molex 43030-0009 MICROFIT TERM Gold 20-24 Plastic Housing - Molex 43025-0200 3.0mm (.118") Pitch Micro-Fit, Jr.™ Receptacle, Dual Row (the Enfora GSM/GPRS SA-GL incorporates a 2-pin configuration) WARNING: When assembling the Molex connector, plug the Positive (+) power lead in the bottom of the Molex connector. Improper connections will render the unit inoperable and will void the product warranty. -
Page 14: Table 1: Gsm Operating Power
GSM1218 Quad-Band SA-GL User Manual The following tables provide the power characteristics of the GSM/GPRS SA-GL modem. Enfora -GL (@ 9 Volts) Average Current (mAmps) Peak Current (Amps) GSM 850 1 TX 1 RX 230 mA 1.42 A @ 32 dBm... -
Page 15: Connecting The Serial Cable
To connect the SA-GL with a local computing device, connect one end (male end) of the 9-wire RS232 Serial Cable to the SA-GL port labeled “Serial” and connect the other end to a computer. Figure 5: Connecting the Serial Cable to SA-GL GSM1218PB001MAN Version 1.04 – 04/05/06... -
Page 16: Connecting The Gsm/Gprs Antenna
The antenna connector on the GSM/GPRS SA-GL modem is SMA Female. The antenna has to be connected to the connector labeled “Antenna” as shown below in Figure 6. GSM1218PB001MAN Version 1.04 – 04/05/06... -
Page 17: Attaching A Microphone/Speaker
To place a voice call, insert a microphone/speaker to the port labeled “MIC AUDIO” as shown below in Figure 7. The plug is a standard 2.5mm audio connector. Many existing mobile phone headsets can be used. Figure 7: Attaching a Headset to the GSM/GPRS SA-GL Module GSM1218PB001MAN Version 1.04 – 04/05/06... -
Page 18: Led Functions
2 screws for securing the device. The other option available is the inclusion of four threaded holes for securing screws to be used to secure the device. Figure 8 - Mounting Dimensions GSM1218PB001MAN Version 1.04 – 04/05/06... -
Page 19: Frequently Asked Questions (Faq)
A. Refer to the “GSM0000AN007 - Enabler-G Status Reporting” application note for details. Q. How do I configure a PPP connection for Windows XP? A. Refer to the “GSM0000AN008 - Enabler-G PPP Configuration for Windows XP” application note for details. GSM1218PB001MAN Version 1.04 – 04/05/06... - Page 20 A. Refer to the “GSM0000AN013 - Enabler-G Sleep Mode Configuration and Use” application note for details. Q. How do I configure the SA-GL for PPP API access without having network connectivity? A. Refer to the “GSM0000AN014 - Anytime PPP API Access” application note for details. GSM1218PB001MAN Version 1.04 – 04/05/06...
-
Page 21: Tech Support
For problems stemming from your network access, contact your GSM/GPRS carrier service. For technical support and customer service dealing with the modem itself, contact the company where you purchased the product. If you purchased the product directly from Enfora, visit the SUPPORT page on the Enfora website: http://www.enfora.com. GSM1218PB001MAN...
