- Page 1 User Manual: GSM1208PB001MAN Enfora GSM1208 Quad-Band SA-G User Manual Revision 1.02 Enfora L.P. 661 E. 18 Street Plano Texas 75074 www.enfora.com...
- Page 2 All specifications are subject to change without notice and do not represent a commitment on the part of Enfora L.P. Enfora L.P. will not be responsible for any loss or damages incurred related to the use of information contained in this document.
- Page 3 Limited Warranty ENFORA L.P. 12-MONTH LIMITED WARRANTY Enfora warrants to the original purchaser of the product that, for a period of one (1) year from the date of product purchase, the product hardware, when used in conjunction with any associated software (including any firmware and applications) supplied by Enfora, will be free from defects in material or workmanship under normal operation.
- Page 4 (iii) caused by use of any software other than any software supplied by Enfora, or by use of the product other than in accordance with its documentation or (iv) the result of electrostatic discharge, electrical surge, fire, flood or similar causes.
- Page 5 GSM1208 Quad Band SA-G User Manual Revision History Revision Release Date Description of Changes Number 1.00 06/03/04 Initial release 1.01 02/14/05 Updated warranty and technical support information 1.02 04/05/06 Added CE Label information GSM1208PB001MAN Version 1.02 – 04/05/06...
-
Page 6: Table Of Contents
Figure 14: GSM1208 SA-G Bracket Installation..........15 Figure 15: GSM1208 SA-G Mounting Bracket (ready to mount)......16 Figure 16: Mounting Bracket Dimensions ............16 Tables Table 1: GSM Operating Power ................7 Table 2: GPRS Operating Power ................7 Table 3: SA-G GPIO Characteristics..............12 GSM1208PB001MAN Version 1.02 – 04/05/06... - Page 7 GSM1208 Quad Band SA-G User Manual GSM1208PB001MAN Version 1.02 – 04/05/06...
-
Page 8: Introduction
Detailed information pertaining to the specifications and operation of the module will pertain, in part, to the GSM1208 SA-G platform. The information can be accessed at the Enfora website under Support/Integrator Downloads. . Refer to the following documentation for additional information, if required:... -
Page 9: System Requirements
• One standard plug for speaker and microphone* *not required for stand alone operation 1.4 Spider SA Front and Back View Figure 1: Front view of GSM1208 SA-G modem. Figure 2: Rear view of GSM1208 Spider SA-G modem. GSM1208PB001MAN Version 1.02 – 04/05/06... -
Page 10: Regulatory Compliance
The modem was tested and certified to meet FCC Parts 15 in a stand-alone configuration, which demonstrated that the GSM1208 SA-G complies with Part 15 emission limits. FCC Part 22 & Part 24 is covered by the Enfora Enabler-IIG "modular approval" process for a transmitter. This approach, described by FCC... - Page 11 GSM1208 Quad Band SA-G User Manual Enfora shall not be liable for consequential or incidental damages, injury to any person or property, anticipated or lost profits, loss of time, or other losses incurred by Customer or any third party in connection with the installation of the Products or Customer's failure to comply with the information and instructions contained herein.
-
Page 12: Installation
GSM service provider and must be provisioned by the operator for data and/or voice. Always take care to protect the SIM: the GSM terminal will not operate without the SIM installed. Figure 3: Inserting a SIM Card in a GSM1208 SA-G Module GSM1208PB001MAN Version 1.02 – 04/05/06... -
Page 13: Connecting The Power Supply
Molex 39-00-0207 MINIFIT TERM CRP FEM CHN BS TIN 18-24 Plastic Housing - Molex 39-01-2020 4.20mm (.165") Pitch Mini-Fit, Jr.™ Receptacle, Dual Row (the Enfora GSM/GPRS Spider SA incorporates a 2-pin configuration) WARNING: When assembling the Molex connector, plug the Positive (+) power lead in the bottom of the Molex connector. -
Page 14: Table 1: Gsm Operating Power
1 RX 76 mA Idle 33 mA DCS 1800 & GPRS 1 TX /1RX 114 mA .68 A @ 28.5 dBm PCS 1900 1 RX 84 mA Idle 33 mA Table 2: GPRS Operating Power GSM1208PB001MAN Version 1.02 – 04/05/06... -
Page 15: Connecting The Serial Cable
(male end) of the 9-wire RS232 Serial Cable to the GSM1208 SA-G port labeled “Serial” and connect the other end to a computer. Figure 5: Connecting the Serial Cable to GSM1208 SA-G The following figure provides the Spider SA serial pinout information. Figure 6: Serial Pinout GSM1208PB001MAN Version 1.02 – 04/05/06... -
Page 16: Connecting The Gsm/Gprs Antenna
The antenna connector on the GSM1208 SA-G modem is SMA Female. The antenna has to be connected to the connector labeled “Antenna” as shown below in Figure 7. Figure 7: GSM1208 SA-G Connecting the Antenna GSM1208PB001MAN Version 1.02 – 04/05/06... -
Page 17: Attaching A Microphone/Speaker
To place a voice call, insert a microphone/speaker to the port labeled “MIC AUDIO” as shown below in Figure 8. The plug is a standard 2.5mm audio connector. Many existing mobile phone headsets can be used. Figure 8: Attaching a Headset to the GSM1208 SA-G Modem GSM1208PB001MAN Version 1.02 – 04/05/06... -
Page 18: Using The Gsm1208 Sa-G Modem I/O Interface
The Wago connector is attached to the SA as shown in Figure 9. Figure 9: Wago I/O Connector Attachment The insertion of a bare wire in the Wago I/O connector is shown in Figure 10. Figure 10: Wago Connector Wire Insertion GSM1208PB001MAN Version 1.02 – 04/05/06... -
Page 19: Figure 11: Gpio Pin Configuration
0.18 0.24 OMIN Analog-To-Digital Input Parameter/Conditions UNIT ADC Binary Resolution Bits BRES Scale factor is 0.02. A reading of 250 = 5 V. ADC Range (±5%) ADC Input Impedance kΩ Table 3: SA-G GPIO Characteristics GSM1208PB001MAN Version 1.02 – 04/05/06... -
Page 20: Led Functions
PWR: Indicates power to the modem. Solid when the modem is turned REG: Indicates GSM network registration status. Flashing when attempting to register on a GSM network. Solid when the modem is registered with a GSM network. GSM1208PB001MAN Version 1.02 – 04/05/06... -
Page 21: Mounting The Gsm/Gprs Spider Sa
Each piece of the bracket can now be inserted at the ends of the unit as demonstrated in Figure 14: GSM1208 SA-G Bracket Installation and Figure 15: GSM1208 SA-G Mounting Bracket (ready to mount). Figure 12: GSM1208 SA-G Mounting Bracket (attached) GSM1208PB001MAN Version 1.02 – 04/05/06... -
Page 22: Figure 13: Gsm1208 Sa-G Mounting Bracket (Separated)
GSM1208 Quad Band SA-G User Manual Figure 13: GSM1208 SA-G Mounting Bracket (separated) Figure 14: GSM1208 SA-G Bracket Installation GSM1208PB001MAN Version 1.02 – 04/05/06... -
Page 23: Figure 15: Gsm1208 Sa-G Mounting Bracket (Ready To Mount)
GSM1208 Quad Band SA-G User Manual Figure 15: GSM1208 SA-G Mounting Bracket (ready to mount) Figure 16: Mounting Bracket Dimensions GSM1208PB001MAN Version 1.02 – 04/05/06... -
Page 24: Frequently Asked Questions (Faq)
A. Refer to the “GSM0000AN007 - Enabler-G Status Reporting” application note for details. Q. How do I configure a PPP connection for Windows XP? A. Refer to the “GSM0000AN008 - Enabler-G PPP Configuration for Windows XP” application note for details. GSM1208PB001MAN Version 1.02 – 04/05/06... - Page 25 A. Refer to the “GSM0000AN013 - Enabler-G Sleep Mode Configuration and Use” application note for details. Q. How do I configure the SA-G for PPP API access without having network connectivity? A. Refer to the “GSM0000AN014 - Anytime PPP API Access” application note for details. GSM1208PB001MAN Version 1.02 – 04/05/06...
-
Page 26: Tech Support
For problems stemming from your network access, contact your GSM/GPRS carrier service. For technical support and customer service dealing with the modem itself, contact the company where you purchased the product. If you purchased the product directly from Enfora, visit the SUPPORT page on the Enfora website: http://www.enfora.com. GSM1208PB001MAN...
