- Page 1 Enfora GSM/GPRS Compact Flash Card Users Manual Version 1.0 Enfora L.P. 661 E. 18 Street Plano Texas 75074 www.enfora.com...
-
Page 2: Disclaimer
Further, Enfora L.P. reserves the right to revise this publication, and to make changes from time to time in the contents hereof without obligation of Enfora L.P. to notify any person of such revision or changes. -
Page 3: Fcc Compliance Statement
CAUTION Changes or modifications without the express consent of Enfora, L.P. voids the user’s authority to use the equipment and will avoid any applicable warranty. This equipment has been tested and found to comply with the limits pursuant to Part 15 Subpart B , Part 22 and Part 24 of the FCC rules. -
Page 4: Safety Instructions
Safety Instructions • Use of radio equipment is prohibited in hospitals and may interfere with the use of medical equipment. Do NOT use the GSM/GPRS Compact Flash Card in hospitals. • FCC regulations prohibit using your wireless device during any air flight. Switch OFF your GSM/GPRS Compact Flash Card prior to flight and in accordance with airlines acceptable devices policy. -
Page 5: General Safety Instructions
General Safety Instructions • Check if all peripherals are properly connected before turning on any equipment. • Make sure to disconnect the power plug from the power source before installing or removing peripherals. • Always hold the product with dry hands. Droplets of water may cause it to short circuit and damage to the product. -
Page 6: Table Of Contents
Copyright Statement ..................... ii Disclaimer ..........................ii FCC RF EXPOSURE INFORMATION ..........iii FCC COMPLIANCE STATEMENT ............ iii Safety Instructions ......................iv Operating Instructions ....................iv General Safety Instructions ..................v Overview ..........................2 Welcome! ......................2 Package Contents ....................3 Appearance ...................... -
Page 7: Overview
Overview Welcome! Thank you for purchasing the GSM0110 GSM/GPRS Compact Flash Card! Welcome to the world of wireless data. Your GSM/GPRS Compact Flash Card is a compact, wireless data modem that uses the GSM/GPRS (General Packet Radio Services) wireless communication system, allowing you to transfer data on the go. Wireless IP (Internet Protocol) supports browser-based applications, giving you feature rich capability with the Internet in your hand. -
Page 8: Package Contents
Package Contents Check the contents of the package. The following items should be included. If there is any item that is damaged or missing, please contact your dealer immediately. Description Quantity The GSM/GPRS Compact Flash Card PCMCIA Adapter BVRP Software CD User Manual Quick Start Guide for Mobile Phone Tools Note:... -
Page 9: Appearance
Appearance The GSM0110 GSM/GPRS Compact Flash Card Battery On/Off Button Holder Connector Headset Antenna Jack Status GSM/GPRS Compact Flash Card... -
Page 10: Network Status (Link) Led Description
Network Status (Link) LED Description Color LED Status Connection Status Blinking Slow Amber Blinking Fast Searching for GSM Network Amber Blinking Slow Connected to GSM Network Green Blinking Slow Connected to GPRS Network Green Blinking Fast Transmitting/Receiving Data Blinking Slow - Once Every 2 second Blinking Fast - 4 times a second Installing and removing the SIM You need to use a SIM (Subscriber Identity Module) card with your GSM/GPRS Compact Flash... -
Page 11: Installing The Cf Card Into The Pda
Installing the CF Card into the PDA To install a PDA 1. Locate the Compact Flash slot on your PDA. 2. Place the Compact Flash card into the slot with the connector part of the card facing down into the slot. 3. -
Page 12: System Requirements
System Requirements Check your hardware and software to see if they satisfy the requirements below. If you are not sure, please consult your dealer or operator. • A valid SIM card that has been data-enabled or voice and data enabled by your network operator. -
Page 13: Compact Flash Card Accessories
Compact Flash Card Accessories Connecting the Optional Headset To make or receive voice calls, you will need to connect the headset (not supplied) to the connector on the GSM/GPRS Compact Flash Card. Battery Operation (Optional Purchase) Prior to using the optional GSM/GPRS Compact Flash Card Battery, charge the new battery for a minimum of 24 hours to obtain a full charge. -
Page 14: Battery Status Led Description
Removing the Battery: 1. Press the battery latch button and pull the battery out of the battery connection slot. 2. Replace the rubber cover on the battery connection slot The battery is charged using a separate A/C adapter that is included with the battery accessory purchase. -
Page 15: Installing Pocket Phonetools For Pocketpc
Installing pocket PhoneTools for PocketPC The software for pocket Phone Tools is located on the CD-ROM labeled BVRP pocket Phone Tools. 1. Connect your PDA to your computer. ActiveSync® must be installed on your PC before installing pocket Phone Tools. 2. - Page 16 5. Read the License Agreement. Select Yes if you agree with the terms of the license agreement. 6. Specify a destination folder for pocket Phone Tools or accept the default folder. Select Next. 7. Setup will now install the software. Select Cancel if you wish to stop the installation process.
- Page 17 8. pocket Phone Tools will connect with your PDA and then copy the files to your PDA. 9. Select Yes to install the BVRP Software pocket Phone Tools. 10. The install progress will be displayed on the PC screen. When the installation is completed you will be prompted to check your PDA. Check to see if there are any additional steps to be performed on your PDA to complete the installation.
-
Page 18: Running Pocket Phonetools
12. When the install is complete, pocket Phone Tools Icon will be located in the Programs Menu of your PDA. Running pocket PhoneTools You will need to configure your Select pocket Phone Tools icon Network Operator. Select Yes to window. from the Programs configure your Network Operator. - Page 19 3. pocket PhoneTools will detect your 4. Select OK to return to the main Network Operator. Select OK and pocket Phone Tools window. you will return to the General Setup window. 6. The main pocket Phone Tools menu will appear. 5.
-
Page 20: Pocket Phonetools Functions
pocket PhoneTools Functions Inbox Items Outbox Items Sent Messages Phonebook Sort Items Messages Displayed Create SMS Retrieve SMS Add phonebook entry Internet Connection Hide Toolbar Dialer Menu GSM/GPRS Compact Flash Card... -
Page 21: Dialer Menu
Dialer Menu Selecting the Dialer Icon from the main menu will launch the Dialer. To have the Dialer load when pocket Phone Tools starts select Tools>Settings> and Select On when loaded. Place a Call Battery Status End a Call Connections Status Clear Number Speaker On/Off... -
Page 22: Creating A Gprs Connection
Creating a GPRS connection 1. In the pocket Phone Tools Taskbar 2. In the General Setup Screen Select Select Tools (1) then Settings (2). Internet Connection. Enter a name for you connection. 3. Select New to create a connection Note: This name is specific to enabling the BVRP software with the GSM/GPRS Wireless Portfolio. - Page 23 Select GPRS connection. Proceed to Select any of the listed applications step 12. If you are using a unique APN or to run once a connection is made. Static IP or DNS go to Step 7. Uncheck Select Next. Use Standard settings to enter a Specific APN, IP or DNS.
- Page 24 9. Configure your DNS information 10. Select Next based on the information provided by your network operator. Select Next. 12. Select No. Check with your network 11. Select Next. operator to see if they support CSD calls. See the FAQ section for more information Note: CSD calls may incur additional charges with your carrier.
- Page 25 13. Select OK to return to the 14. Select OK. General Setup window. 15. Select the Globe Icon to 16. Connection status will be start your Internet Connection. displayed in the Task Bar. Start Internet Connection GSM/GPRS Compact Flash Card...
-
Page 26: Troubleshooting
Troubleshooting If you have any questions regarding installation, set up, or operation of the GSM/GPRS Compact Flash Card, please contact Enfora Technical Support. Website: http://www.enfora.com Voice: (972) 578-2873 Email: techsupport@enfora.com North America Email: support.europe@enfora.com European Union GSM/GPRS Compact Flash Card... -
Page 27: Warranty Information
(ii) caused by any accident, misuse, abuse, improper installation, handling or testing, or unauthorized repair or modification of the product, (iii) caused by use of any software other than any software supplied by Enfora, or by use of the product other GSM/GPRS Compact Flash Card... - Page 28 DAMAGES (INCLUDING WITHOUT LIMITATION LOSS OR INTERRUPTION OF USE, DATA, REVENUES OR PROFITS) RESULTING FROM A BREACH OF THIS WARRANTY OR BASED ON ANY OTHER LEGAL THEORY EVEN IF ENFORA HAS BEEN ADVISED OF THE POSSIBILITY OR LIKELIHOOD OF SUCH DAMAGES.
