Integration Guide:
EDG0308IG001
Enfora Enabler IIIE
Integration Guide
Version: Draft

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Enabler IIIE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enfora Enabler IIIE

Summary of Contents for Enfora Enabler IIIE

  • Page 1 Integration Guide: EDG0308IG001 Enfora Enabler IIIE Integration Guide Version: Draft...
  • Page 2 All specifications are subject to change without notice and do not represent a commitment on the part of Enfora, Inc. Enfora, Inc. will not be responsible for any loss or damages incurred related to the use of information contained in this document.

  • Page 3: Table Of Contents

    MANUAL OVERVIEW............................4 3.1............................4 EVISION ISTORY 3.2..........................5 EFERENCE OCUMENTS 3.2.1. Enfora Enabler IIIE Product Documentation..................5 3.2.2. GSM Device Specifications........................6 3.2.3. US Government............................6 3.2.4. Federal Communications Commission (FCC)..................6 3.2.5. FCC Office of Engineering and Technology (OET) ................6 3.2.6. Industry Canada ............................6 3.2.7.
  • Page 4 ODULE ARRIER 6.8.1. SIM Integration for the Enfora Enabler IIIE Module................50 6.8.2. Using a Remote SIM with the Enfora Enabler IIIE Module (Pins 76, 78, 80, 82, 84)......50 6.8.2.1. Remote SIM Component Information......................52 GSM/GPRS MODES OF OPERATION ......................53 7.1.
  • Page 5 (OEM)..........69 NSTRUCTIONS TO THE RIGINAL QUIPMENT ANUFACTURER 13.8.1. OEM Responsibilities for All Products Containing the Enabler IIIE module ........71 13.8.2. Specific OEM Responsibilities for Portable Products and Applications ..........72 13.8.3. Specific OEM Responsibilities for Mobile Products and Applications..........72 13.8.4. Specific OEM Responsibilities for Fixed Products and Applications..........72 13.9.

  • Page 6: Safety Precautions

    2. Regulatory Compliance FCC 2.1. Integration Considerations and Installation Requirements The Enabler IIIE modem is designed for use in a variety of host units, "enabling" the host platform to perform wireless data communications. However, there are certain criteria relative to ®...
  • Page 7 Enfora Enabler IIIE Modem Integration Guide • If used in a "mobile" application where the antenna is normally separated at least 20 cm (7.9 in) from the human body during device operation, then an appropriate warning label must be placed on the host unit adjacent to the antenna. The label...

  • Page 8: Disclaimer

    PTCRB, R&TTE, IMEI and other applicable codes that are in effect at the time of publication. Enfora disclaims all responsibility for any act or omissions, or for breach of law, code or regulation, including local or state codes, performed by a third party.

  • Page 9: Manual Overview

    Modem Integration Guide 3. Manual Overview This document describes the hardware interface of the Enabler IIIE modem. The purpose of this document is to define the electrical, mechanical and software interfaces while providing detailed technical information in order to streamline the process of hardware and system integration.

  • Page 10: Reference Documents

    Enfora Enabler IIIE Modem Integration Guide 3.2. Reference Documents 3.2.1. Enfora Enabler IIIE Product Documentation Manuals • EDG0308AT001 - Enfora Enabler IIIE AT Command Set EDG0308IG001 Draft – 03/07/2008...

  • Page 11: Gsm Device Specifications

    Enfora Enabler IIIE Modem Integration Guide 3.2.2. GSM Device Specifications • 3GPP TS 51010-1 (850, 900,1800,1900 MHz devices) To view the latest release, go to: http://www.3gpp.org/ftp/Specs/html-info/51010-1.htm 3.2.3. US Government 3.2.4. Federal Communications Commission (FCC) Internet: http://www.fcc.gov/ • FCC Rules, Part 24 •...

  • Page 12: Mechanical Specifications

    Enfora Enabler IIIE Modem Integration Guide 3.2.8. Mechanical Specifications • ASTM D999 • ASTM D775 • IEC 68-2-27 • Bellcore Gr-63-CORE • ETS 300 019-1-1 Class 1.2 • ETS 300 019-1-2 Class 2.1 • ETS 300 019-1-3 Class 3.1 3.2.9.

  • Page 13: Introduction

    GSM services. The Enfora Enabler IIIE module is a fully Type- approved GSM/GPRS/EDGE device, enabling application-specific, two-way communication and control. The small size of the Enfora Enabler IIIE module allows it to be integrated easily into the application and packaging. 4.2.
  • Page 14 Handset microphone input (MICIN, MICIP pins) • Headset microphone input (HSMIC pin) Outputs • Handset earphone outputs (EARP, EARN pins) • Headset 32 Ω stereo outputs (HSOL, HSOR pins) Table 1 - Enabler IIIE Key Features EDG0308IG001 Draft – 03/07/2008...

  • Page 15: Wireless Data Application Possibilities

    Enfora Enabler IIIE Modem Integration Guide 4.3. Wireless Data Application Possibilities A variety of applications can use the Enfora Enabler IIIE module for transmitting/receiving data/voice, such as: Automated Meter Reading (AMR) • • Point of Sale Applications E-mail and Internet access •...

  • Page 16: Summary Of Features For The Enabler Iiie Module

    Enfora Enabler IIIE Modem Integration Guide 4.4. Summary of Features for the Enabler IIIE Module The following summarizes the main features of the Enfora Enabler IIIE Module. Mechanical Dimensions........34mm (L) x 28mm (W) x 2.5mm (H) Weight .......... 4.8 grams Packet Data Transfer: Protocol……………………………………………GPRS Release 99, EGPRS Release 4...
  • Page 17 Enfora Enabler IIIE Modem Integration Guide Application Interface: Host Protocol........ AT Commands Internal Protocols ......PPP and CMUX Physical Interface......1 serial UART primary (default baud rate 460800), 1 Serial Debug (RX and TX only) Audio Interface......Handset microphone input (MICIN, MICIP pins), Headset microphone input (HSMIC pin), Handset earphone outputs (EARP, EARN pins), Headset 32 Ω...

  • Page 18: General Design Guidelines For Utilizing Enfora Gsm Modules

    4.5. General design guidelines for utilizing Enfora GSM modules The following guidelines are provided in an effort to allow Enabler IIIE module users to successfully implement their PCB layout to obtain the best performance. This includes the lowest possible EMI emissions, maximum thermal conduction, mechanical integrity, and voice quality.

  • Page 19: Advanced Tips For An Rf Friendly Layout

    Enfora Enabler IIIE Modem Integration Guide 4.5.1. Advanced Tips for an RF Friendly Layout 4.5.1.1. Ground Plane To ensure the lowest possible EMI emissions and maximum thermal conductivity, it is recommended that all metal tabs on the GSM module shield must be soldered down onto a continuous ground plane that runs under the entire module.

  • Page 20: Figure 2 - Example Of A Poor Rf Thermal Relief

    Enfora Enabler IIIE Modem Integration Guide For example, a large thermal relief like the one shown in Figure 2 can serve the purpose for general applications such as low current, low speed data lines, DC connections and audio frequency applications. Such thermal relief structures should be avoided for applications where high current and/or high frequency is involved, such as those using the Enabler Module.

  • Page 21: Antenna And Rf Signal Trace

    Enfora Enabler IIIE Modem Integration Guide GOOD RF thermal relief Figure 3 - Example of a GOOD RF Thermal Relief 4.5.1.3. Antenna and RF Signal Trace The PCB trace that feeds the RF output port must be designed for a 50 ohm characteristic impedance, coplanar, or routed into internal layers to keep the top layer continuous around and underneath the Enabler module.

  • Page 22: Vbat Input

    Enfora Enabler IIIE Modem Integration Guide If multiple antennas are used in their design, care should be taken during placement selection to minimize the coupling between the GSM antenna and the other antennas. 4.5.1.4. Vbat Input The Enabler Vbat input can have a relative high current draw that can fluctuate rapidly, especially when transmitting at max power and burst mode.

  • Page 23: Figure 5 - Example Of Good Vbat Layout

    Enfora Enabler IIIE Modem Integration Guide Since even the best layout will have some impedance from the source to the Enabler module, sufficient bulk decoupling capacitance is required at the Vbat input to the Enabler module. It is suggested to use at least two 1000 uF, low ESR, tantalum capacitors located very close to the Enabler interface connector Vbat pins.

  • Page 24: Audio Reference Design

    Enfora Enabler IIIE Modem Integration Guide 4.5.2. Audio Reference Design The audio quality is very dependent on the circuit design and layout. As an aid to obtaining good audio quality, a reference design has been included below. It has been proven to provide good performance on the SDK module.

  • Page 25: Audio Layout

    Enfora Enabler IIIE Modem Integration Guide 4.5.2.2. Audio Layout Layout plots for the audio section of the SDK are available upon request. 5. Technical Specifications 5.1. Detailed Product Specifications Physical Dimensions and Weight Size (L x W x H) 34mm x 28mm x 2.5mm Weight Without SIM Connector –...

  • Page 26: Typical Operating Power

    Enfora Enabler IIIE Modem Integration Guide Typical Operating Power 5.1.1. Input Voltage Range The modem operates within performance specifications over the input voltage range of: Input Voltage Range 3.3 to 4.5 Vdc CAUTION: Any excursions above or below this range may cause the module to deviate from RF performance specifications and/or cause damage to the module.

  • Page 27: Gsm Receiver Sensitivity

    1 RX/1TX, Full Power DRX2 Idle 3.55 DRX5 Idle 2.15 DRX9 Idle 1.78 Shutdown 1420 5.1.2. GSM Receiver Sensitivity Enfora Enabler IIIE module Sensitivity 1900 MHz -106 dBm (typical) 1800 MHz 900 MHz -106 dBm (typical) 850 MHz EDG0308IG001 Draft – 03/07/2008...

  • Page 28: Mechanical

    Enfora Enabler IIIE Modem Integration Guide 6. Mechanical Figure 7 shows the mechanical footprint for the module. The outline dimensions are applicable to the module with and without the onboard SIM holder. Figure 7 – Side View and Top View EDG0308IG001 Draft –...

  • Page 29: Figure 8 - Side View And Top View

    Enfora Enabler IIIE Modem Integration Guide Figure 8 – Side View and Top View EDG0308IG001 Draft – 03/07/2008...

  • Page 30: Module Mounting To Host Board (Reference)

    Enfora Enabler IIIE Modem Integration Guide 6.1. Module Mounting to Host Board (Reference) The module provides mounting tabs that must be soldered to a PCB. These tabs provide circuit grounding for the module. Figure 9 – Module Mounting EDG0308IG001 Draft – 03/07/2008...

  • Page 31: Figure 10 - Shield Mounting Pads

    Enfora Enabler IIIE Modem Integration Guide Figure 10 - Shield Mounting Pads EDG0308IG001 Draft – 03/07/2008...

  • Page 32: Figure 11 - Host Pads For Board-To-Board Rf Connector

    Enfora Enabler IIIE Modem Integration Guide Figure 11 - Host Pads for Board-To-Board RF Connector EDG0308IG001 Draft – 03/07/2008...

  • Page 33: Connectors

    Enfora Enabler IIIE Modem Integration Guide 6.2. Connectors On The Modem: 100-Pin I/O Connector, Plug, SMT, Dual Row, 0.4 mm Pitch Enfora PN = CON-1040-0100 Molex PN = 55909-1074 On The Host: 100-Pin I/O Connector, Socket, SMT, Dual Row, 0.4 mm Pitch (Mate to module)

  • Page 34: I/O Connector Pin Assignments

    Enfora Enabler IIIE Modem Integration Guide 6.3.3. I/O Connector Pin Assignments The following table shows the pin assignments for the input/output connector. Table 2 - Enabler IIIE Pin Assignments Pin # Serial Enabler IIIE Description/Comments (Default Function / Secondary Function VBUS USB power –...
  • Page 35 Enfora Enabler IIIE Modem Integration Guide Pin # Serial Enabler IIIE Description/Comments (Default Function / Secondary Function HSMICBIAS Headset microphone bias System ground HSMIC Microphone input (Headset) CLK32K_BUF 32.768 kHz out, only buffered by 10 kΩ resistor HSOL 32 kΩ headset amplifier Left...

  • Page 36: Circuit Protection

    47, 49, 51, 52, C101-A 53, 55 – 57, 59, 61, 63, 65, 67 Caution – It is the Integrator’s responsibility to protect the Enabler IIIE module from electrical disturbances and excursions, which exceed the specified operating parameters. EDG0308IG001 Draft – 03/07/2008...

  • Page 37: Antenna

    Module Power (Pins 85, 87, 89, 91, 93, 95, 97, 99) The Enfora Enabler IIIE module uses a single voltage source of VCC=+3.3V to 4.5V. (The exact values of the uplink currents are shown in the tables in section 5.3.1.)

  • Page 38: Reset Signal (Pin 37)

    Enfora Enabler IIIE Modem Integration Guide 6.7.2. Reset Signal (Pin 37) The Reset signal is used to force the modem to start at a known state. When the Reset is pulled low the modem will immediately suspend any function and will not exit the reset state until the Reset signal is released to be pulled high.

  • Page 39: Power Control (Pin 35) (Pwr_Ctl)

    6.7.3.2. Turning OFF the Enabler IIIE The Enabler IIIE can be turned off by either a low pulse on the PWR_CTL line, or by a software command (AT$OFF, see AT guide for further details). Section 6.7.3.3 describes various ways to provide the signal.

  • Page 40: Using The Power Control Signal

    Enfora Enabler IIIE Modem Integration Guide 6.7.3.3. Using the Power Control Signal Typical use powering module on/off with a switch: Figure 12 – Power Control Switch EDG0308IG001 Draft – 03/07/2008...

  • Page 41: Figure 13 - External Power Control Signal (No External Processor)

    Float RESET Figure 13 - External Power Control Signal (no external processor) shows a typical connection to the Enfora Enabler IIIE module in a machine-to-machine application using the external PWR_CTL signal, when there is not an external processor controlling the power on/off states. The RTC deep sleep functions will NOT function since the PWR_CTL pin is tied low, the processor will never stay in a “RTC Sleep”...

  • Page 42: Figure 14 - Power Control Signal (Using External Processor)

    Figure 14 - Power Control Signal (using external processor) shows a typical connection from an external processor to the Enfora Enabler IIIE module, using the external PWR_CTL signal. The Enfora Enabler IIIE can be powered on by using the PWR_CTL signal, and reset with the RESET signal. When using PWR_CTL, the I/O or serial lines can be at any voltage state desired.

  • Page 43: Level Translation Reference Power (Pin 77)

    Enfora Enabler IIIE Modem Integration Guide 6.7.4. Level Translation Reference Power (Pin 77) To be used as a voltage reference source ONLY. Do not connect current loads to this pin. This pin must be decoupled to ground with at least a 0.1 μF capacitor at the output. Noise induced on this pin will affect the performance of the baseband.
  • Page 44 Enfora Enabler IIIE Modem Integration Guide USB Power (pins 1,3) Parameter/Conditions Units Connected from VRUSB to Filtering Capacitor µF GNDD Filtering Capacitor ESR mΩ Input Voltage V ON mode, in regulation 5.25 B-Device (SRP Capable, 0 V ≤ VBUS ≤ 5.25 V...
  • Page 45 Enfora Enabler IIIE Modem Integration Guide USB Port In Input Levels Parameter/Conditions Units Serial Interface Input High RXD Input High On Serial Interface Input Low RXD Input Low On Output Levels Parameter/Conditions Units Serial Interface Input = 4 mA SOURCE...

  • Page 46: General Purpose Input/Output Interface

    Serial Interfaces & Handshake (Pins 15, 21, 13, 11, 17, 25, 19, 23) In an effort to make the naming convention less confusing for integrators, the Enabler IIIE is referenced as the DTE (similar to Enabler II products) as opposed to the enabler IIIG that was originally referenced as a DCE.

  • Page 47: Ring Indicate (Pin 23)

    Rated Output Current 6.7.8. Ring Indicate (Pin 23) The Enabler IIIE module is capable of using the Ring line to discern the type of incoming call. The indicator can be monitored via a hardware line available on the 100-pin I/O signal connector.

  • Page 48: Figure 15 - Ring Indicate Timing

    Enfora Enabler IIIE Modem Integration Guide When the module is receiving a voice call, the Ring line goes low for 1 second and high for another 2 seconds. Every 3 seconds the ring string is generated and sent over the Receive (Data Out) (Rx) line.

  • Page 49: Vbackup

    Enfora Enabler IIIE Modem Integration Guide 6.7.9. VBACKUP is a backup voltage input that can maintain the RTC clock and alarm functions. If V is not BACKUP BACKUP present in the system (intentionally or not) the RTC clock may still be powered if leakage voltage exists on VCC.

  • Page 50: 32 Khz Output (Pin 56)

    Enfora Enabler IIIE Modem Integration Guide 6.7.10. 32 kHz output (Pin 56) A 32.768 kHz signal is available as an output from the module. This signal should only be used as an input to a high impedance device. Additional loads or capacitance on the line may cause performance issues with the module.

  • Page 51: Handset Microphone Bias Output (Pin 63)

    Enfora Enabler IIIE Modem Integration Guide 6.7.13. Handset Microphone Bias Output (Pin 63) Mic Bias Output Parameter/Conditions Units Bias Voltage on Mic(+) Set to 2.0 V Set to 2.5 V Mic Bias Current Capability 6.7.14. Handset Speaker Output (Pins 71, 73)

  • Page 52: Headset Microphone Input (Pin 55)

    Enfora Enabler IIIE Modem Integration Guide 6.7.15. Headset Microphone Input (Pin 55) The headset differential inputs HSMIC and AUXI can be amplified by the differential handset microphone amplifier. This amplifier has two different gains 4.9 dB or 25.6 dB and a bias generator HSMICBIAS provides an external voltage of 2 V or 2.5 V to bias the microphone.

  • Page 53: Headset Speaker Output Left & Right (Pins 57, 59)

    Enfora Enabler IIIE Modem Integration Guide 6.7.17. Headset Speaker Output Left & Right (Pins 57, 59) Pin Name Pin Number Signal Direction Description HSOL Headset Out 32Ω Speaker Left HSOR Headset Out 32Ω Speaker Right HSOVMID Headset Out pseudo ground return The left and right headset amplifiers provide the stereo signal on terminals HSOL and HSOR.

  • Page 54: Headset Detect (Pin 47)

    Enfora Enabler IIIE Modem Integration Guide 6.7.19. Headset Detect (Pin 47) Headset Plug/Unplug detection. This pin is used to automatically switch to the headset audio path when enabled with AT$VSELECT=4. The device will default to handset when no Headset is detected.

  • Page 55: Subscriber Identity Module (Sim) Carrier (Pins 76, 78, 80, 82, 84)

    Note: The SIM is not provided with the Enfora Enabler IIIE module. The SIM must be obtained from the GSM service provider and must be provisioned by the operator for data and/or voice.

  • Page 56: Figure 16 - Remote Sim Interface

    Enfora Enabler IIIE Modem Integration Guide <25.4 cm (10 in) Enabler IIIE Remote SIM module SIM_VDD Interface SIM_RST SIM_CLK SIM_DTC SIM_I/O Figure 16 - Remote SIM Interface Pin Name Pin Number Signal Direction Description SIM_VDD SIM VDD SIM_CLK Card Reference Clock...

  • Page 57: Remote Sim Component Information

    Debouncing time (SIM-card extraction) Detect Pull-up resistor (resistor + resistive switch) kΩ 6.8.2.1. Remote SIM Component Information Any compatible SIM carrier can be used in conjunction with the Enabler IIIE module. For example: Lumberg P/N 8840_A_21. or Suyin P/N: 254016MA006G103ZL EDG0308IG001...

  • Page 58: Gsm/Gprs Modes Of Operation

    Full-Rate (FR), Enhanced Full-Rate (EFR), Half-rate (HR) and Adaptive Multi-rate (AMR). 7.3. Circuit-Switched Data In this mode, the Enfora Enabler IIIE module supports both of the connection modes of transmission that are provided by GSM: • Non-Transparent mode delivers a constantly low error rate but with a non-guaranteed throughput or delay.

  • Page 59: Sms: Short Message Services

    Mobile-terminated (MT): allows receiving a service request (such as, receiving a phone call or an SMS) It is imperative for the Enfora Enabler IIIE module that the SIM be configured for the optional services that are required for the application.

  • Page 60: Gprs Services Supported By The Enfora Enabler Iiie Module

    Modem Integration Guide 8.3. GPRS Services Supported by the Enfora Enabler IIIE Module The Enfora Enabler IIIE module supports the following GPRS (modes of operation) that must be enabled by the operator: GPRS Packet Connectivity (MO and MT) with Both Dynamic and Static IP option •...

  • Page 61: Software Interface

    Enfora EDG0308AT001 - Enfora Enabler IIIE AT Commands. 9.3. Enfora AT Command Set For a full description of the AT commands, refer to the Enfora EDG0308AT001 - Enfora Enabler IIIE AT Commands. Note: A command description that includes an *asterisk denotes that the GSM service provider must enable supplementary services functionality before the command is available.

  • Page 62: Setup And Initialization

    10.1.1. HyperTerminal Configuration for Enabler IIIE module The following provides an example for setting up a Windows HyperTerminal session that can be used to experiment with various configurations on the Enabler IIIE module for controlling computer: 1. Select the connection interface, Direct to Com 1 (or whatever port is the serial port).

  • Page 63: Initialization (At Command Interface)

    In the following examples, “Entry” refers to the application. The following convention describes the direction of the data exchange: • The data exchange from the customer application to the Enfora Enabler IIIE module is designated as: Entry The data exchange from the Enfora Enabler IIIE module to the customer application is...

  • Page 64: Initial Response To The At Command

    In the following examples, the <CR> and <CR><LF> are intentionally omitted for clarity and space. 10.1.3. Initial Response to the AT Command After power is applied to the Enfora Enabler IIIE module, the module performs a power-up self- test. The self-test completes within one (1) second. When queried with the AT command, the Enfora Enabler IIIE module responds with one of the following result codes: •...

  • Page 65: Setting Up The Communication Mode For The Enfora Enabler Iiie Module

    Modem Integration Guide 10.1.5. Setting Up the Communication Mode for the Enfora Enabler IIIE Module The following example sequence provides the AT command and response for setting the Enfora Enabler IIIE module for full phone functionality, automated operator selection, 9600 baud, non- transparent mode.

  • Page 66: Gsm/Sms Examples

    Enfora Enabler IIIE Modem Integration Guide 10.2. GSM/SMS Examples 10.2.1. Initialize the Enfora Enabler III-G Module to Send and Receive SMS Text Messages This topic is addressed in the Enfora Application Note GSM0000AN004 SMS Configuration and Use. 10.2.2. Managing SMS Messages This topic is addressed in the Enfora Application Note GSM0000AN004 SMS Configuration and Use.

  • Page 67: Integration And Testing

    Modem Integration Guide 11. Integration and Testing The Enfora Enabler IIIE module has been designed to minimize the amount of time required for integration and testing the application. By being fully certified by the appropriate bodies, the Enfora Enabler IIIE module provides seamless integration into the GSM network.
  • Page 68 Filter the SIM VCC signal with a 10 uf / 10 V capacitor to help with the line length. Primary and The Enfora Enabler IIIE module uses a 1.8V digital interface. The RS-232 secondary serial signals must be level-shifted to get standard levels. These signals must be Interfaces ESD-protected.

  • Page 69: Appendix A - Limited Warranty

    12.1. Scope Enfora warrants to the original purchaser of the product that, for a period of one (1) year from the date of product purchase, the product hardware, when used in conjunction with any associated software (including any firmware and applications) supplied by Enfora, will be free from defects in material or workmanship under normal operation.

  • Page 70: Other Considerations

    Exceptions and Disclaimers Enfora shall have no obligation under this limited warranty for (a) normal wear and tear, (b) the cost of procurement of substitute products or (c) any defect that is (i) discovered by purchaser during the...

  • Page 71: Appendix B - Regulations And Compliance

    13.2. Electromagnetic Compatibility (EMC) and Safety Requirements The Enfora Enabler IIIE module has been tested and approved for application in the United States of America (US) and the European Union (EU). The compliance details for each of these markets follow. For other markets, additional or alternative regulatory approvals may be required. Always ensure that all rules and regulations are complied with in every country that the OEM application is to be operated.

  • Page 72: Human Exposure Compliance Statement

    Regulations. This certification is contingent upon installation, operation and use of the Enfora Enabler IIIE module and its host product in accordance with all instructions provided to both the OEM and end user. When installed and operated in a manner consistent with the instructions provided, the Enfora Enabler IIIE module meets the maximum permissible exposure (MPE) limits for general population / uncontrolled exposure at defined in Section 1.1310 of the FCC Rules and Regulations.

  • Page 73: Unintentional Radiators , Part 15

    Equipment designated as Class A is intended for use in a commercial, industrial or business environment. The Enfora Enabler IIIE module has been tested and found to comply with the limits for a Class A digital device and can be integrated into equipment or applications intended for use in commercial, industrial or business environments.

  • Page 74: Instructions To The Original Equipment Manufacturer (Oem)

    Both of these documents are available via the Internet at the OET web site: http://www.fcc.gov/oet The Enfora Enabler IIIE products are GSM radio transceivers, which operate under the authority of 47 CFR Part 24, Subpart E and Part 22 of the FCC Rules and Regulations. When installed and operated in accordance with the instructions provided in this manual, these devices comply with current FCC regulations regarding human exposure to radio frequency radiation.
  • Page 75 Enfora Enabler IIIE Modem Integration Guide Note: Additional care must be taken by the installer and/or user of the Enfora Enabler IIIE products to ensure proper antenna selection and installation. Adherence to the above conditions is necessary to comply with FCC requirements for safe operation regarding exposure to RF radiation.

  • Page 76: Oem Responsibilities For All Products Containing The Enabler Iiie Module

    For fixed applications (2 meter separation) the antenna gain can be as much as 26 dBi. radiation Modifications and/or additions to the Enfora Enabler IIIE GSM transceiver, including use of antennas with higher gain than those authorized by the FCC, are prohibited...

  • Page 77: Specific Oem Responsibilities For Portable Products And Applications

    Current FCC regulations limit the EIRP of mobile devices to 2 W. Because the nominal RF output power of the Enfora Enabler IIIE GSM1900 GSM transceiver is 1.0 W (31 dBm), antenna gain for mobile products and applications cannot exceed 2 dBi.

  • Page 78: Emc/Safety Requirements For The Countries Of The European Union (Eu)

    In most other countries that have not been listed above there are similar rules and regulations that must be met for importing the Enfora Enabler IIIE module. Each may require a different mark of approval (for example, the CB Scheme) as an acceptance requirement. For each of these cases the country should identified, and the appropriate steps should be taken to meet the requirements set forth in the intended market.

  • Page 79: Appendix C - Glossary And Acronyms

    Application Programming Interface. App Application Refers to the Application which sends or receives commands/responses from the Enfora Enabler IIIE Module AT Command Set Commands issued by intelligent device to a modem to perform functions, such as to initiate call, to answer call, or to transmit data.
  • Page 80 Enfora Enabler IIIE Modem Integration Guide IMEI A unique number for each GSM Terminal tracked by the GSM operators in International Mobile their Equipment Identity Register (EIR) database. Equipment Identity IMSI A unique number identifying the subscriber stored in the SIM card. Number International Mobile is used in conjunction with the network for call routing.

  • Page 81: Appendix D - Tables And Figures

    Enfora Enabler IIIE Modem Integration Guide 15. APPENDIX D – Tables and Figures FIGURES Figure 1 - Example of good ground plane for GSM modules ..............14 Figure 2 - Example of a POOR RF Thermal Relief..................15 Figure 3 - Example of a GOOD RF Thermal Relief ..................16 Figure 4 - Example of Vbat Voltage Droop ....................

  • Page 82: Appendix E - Contacting Enfora

    16. APPENDIX E - Contacting Enfora For technical support and customer service dealing with the modem itself, contact the company where you purchased the product. If you purchased the product directly from Enfora, visit the SUPPORT page on the Enfora website: http://www.enfora.com/support_newissue.asp...
