Possible Next Steps

A 36-pin Texas Instruments (TI) IP network camera connector can also be used. This con-

nector allows the DSIB to interface to a TI ISP base board. This requires a flat cable connec-

tion and a TI IP network camera board. When the DSIB is used with the TI ISP base board, the

DSIB is not plugged into the HDR-60 Base Board. For further information, see EB69, MachXO2

Dual Sensor Interface Board User' s Guide. For details on the TI IP network camera, visit www.

ti.com/ipcamera.
