6. Run Lattice Diamond
FPGA on the HDR-60 Base Board with the parallel-to-HDMI bitstream which can be found
at www.latticesemi.com/dualsensorbridge. The MachXO2 device on the DSIB is prepro-
grammed to support one 9MT024 NanoVesta sensor. For details on supporting two sensors
or other NanoVesta boards, go to www.latticesemi.com/dualsensorbridge.
Visit www.latticesemi.com/dualsensorbridge for further information on the DISB and the latest
design software or to download EB69, MachXO2 Dual Sensor Interface Board User' s Guide.

Run the Demonstration

After the AC adapter is plugged in and the HDMI/DVI cable is connected, the DSIB sensor' s
input will be seen on a monitor. When the DSIB is running, the two LEDs on the DISB will
be on, indicating that the device and sensor are running correctly.

Other DSIB Features

• FTDI USB for programming the MachXO2 device. This is only possible if the DSIB is
powered-up by the HDR-60 Base Board.
Done!
Congratulations! You have successfully connected and demonstrated the MachXO2 Dual
Sensor Interface Board. Please refer to the MachXO2 Dual Sensor Interface Board User' s Guide
available on the Lattice website at www.latticesemi.com/dualsensorbridge for the following:
• Schematic details
• Gerber PCB layout artwork
• Documentation for supporting two sensors and other NanoVesta sensor boards
• JEDEC files for the MachXO2 to support other NanoVesta boards
® Programmer software on the PC and program the LatticeECP3™
HDMI/DVI Cable
MachXO2 Dual Sensor
Interface Board
