Features and Benefits
• Allows you to connect an existing Ultra ATA 133/100/66 hard
disk drive to a Serial ATA controller of any brand and
supports data rates up to 133 MB/s
• Use this adapter with a SIIG Serial ATA controller to maximize
device support
• Compliant with Serial ATA specification, revision 1.0
• Works with any Serial ATA-enabled system
• Plugs into the 40-pin connector of an Ultra ATA hard disk drive.
No PCI slot is required.
System Requirements
• Serial ATA-enabled Pentium or equivalent PC with an available
Serial ATA port
• Windows 98/98SE/ME/NT 4.0/2000/XP
Package Contents
• (1) Serial ATA-to-Ultra ATA Adapter
• (1) Serial ATA cable
• (1) "Y" split power cable
• This quick installation guide
Anti-Static Precaution
Static Electricity Discharge may permanently damage your system. To
avoid possible static electricity discharge during the installation,
please follow the guidelines below:
• Discharge any static electricity build up in your body by
touching a large grounded metal surface or the computer's case
(if plugged in), for a few seconds.
• During the installation, avoid any contact with internal parts.
Handle cards only by their external edges.
04-0261C
Serial ATA-to-Ultra ATA Adapter
Quick Installation Guide
1
Advertisement
Table of Contents
Related Manuals for SIIG CN2502
Summary of Contents for SIIG CN2502
- Page 1 Serial ATA controller of any brand and supports data rates up to 133 MB/s • Use this adapter with a SIIG Serial ATA controller to maximize device support • Compliant with Serial ATA specification, revision 1.0 •...
- Page 2 Device Connection Before you start, turn OFF your computer and any other connected peripheral devices. Unplug the computer's power cord. For best results, make sure the driver for your existing Serial ATA controller is properly installed. 1. Connect the Serial ATA cable and the mini-size power cable to the Serial ATA-to-Ultra ATA Adapter.
- Page 3 SIIG. See SIIG's Limited 5-year Warranty card for more information. Online Store SIIG offers all of our products online at our company store. Visit us at http://onlinestore.siig.com to find our complete line of products, including hard to find items and accessories (power...
- Page 4 Fremont, CA 94538-3152 Serial ATA+Ultra ATA Adapter is a trademark of SIIG, Inc. SIIG and SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation.
