Introduction
The 4-in-1 Connectivity Adapter for Galaxy Tablets
is a portable and easy way to import images,
videos, music and other files onto Galaxy Tablets.
Features and Benefits
•
LED activity indicator for Host/SD/
MicroSD/Sync/Charging
•
Micro USB port for fast synching and
charging via AC adapter (AC adapter not
included)
•
Compatible with Galaxy Tab 7.0/7.0 Plus/
7.7/8.9/10.1, Galaxy Tab 2 7.0/10.1 and
Windows 8/7/Vista/XP and Mac OS 10.5
and above computers
Package Contents
•
4-in-1 Connectivity Adapter for Galaxy Tablets
•
Micro-USB cable
•
Quick installation guide
04-0804B
4-in-1 Connectivity Adapter
for Galaxy Tablets
Quick Installation Guide
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SIIG CE-AD0012-S1
Summary of Contents for SIIG CE-AD0012-S1
-
Page 1: Quick Installation Guide
4-in-1 Connectivity Adapter for Galaxy Tablets Quick Installation Guide Introduction The 4-in-1 Connectivity Adapter for Galaxy Tablets is a portable and easy way to import images, videos, music and other files onto Galaxy Tablets. Features and Benefits • LED activity indicator for Host/SD/ MicroSD/Sync/Charging •... -
Page 2: Led Indicator
Layout Figure 1: Layout 30-pin Connector: Connects to your Galaxy Tablet's 30-pin connector LED Indicator: - Green: The Connectivity Adapter is active - Red: Indicates SD or MicroSD inserted - Blue: Indicates Micro USB connection USB Host: Connect digital camera, USB drive, keyboard or mouse MicroSD Card Slot: Connects to your MicroSD card... - Page 3 Using USB Drive or Digital Camera Connect the 4-in-1 Connectivity Adapter for Galaxy Tablets' 30-pin Connector to the Galaxy Tab's 30-pin Connector. The green LED will light up. Connect your USB drive or Digital Camera to the USB Type-A connector. The Galaxy Tab will recognize the USB drive or the Digital Camera.
- Page 4 Using SD or MicroSD Card Connect the 4-in-1 Connectivity Adapter for Galaxy Tablets' 30-pin Connector to the Galaxy Tab's 30-pin Connector. The green LED will light up. SD: Insert memory card with the gold pins facing down into the SD slot. The green LED will turn to red.
- Page 5 Figure 3: Connecting SD and MicroSD Charging using an AC Adapter Connect the Micro-USB cable (included) between the Micro-USB port of the 4-in-1 Connectivity Adapter for Galaxy Tablets and your AC adapter. Connect the 4-in-1 Connectivity Adapter for Galaxy Tablets' 30-pin Connector to the Galaxy Tab's 30-pin Connector.
- Page 6 Note: The 4-in-1 Connectivity Adapter will not read a device while charging. Warning: The 4-in-1 Connectivity Adapter for Galaxy Tablets only supports ONE device connection at any one time. Inserting more than one device is not supported. Using a USB Keyboard and Mouse Connect the 4-in-1 Connectivity Adapter for Galaxy Tablets' 30-pin Connector to the Galaxy Tab's 30-pin Connector.
-
Page 7: Technical Support And Warranty
Go to www.siig.com, click Support, then REQUEST A PRODUCT REPLACEMENT to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request will be processed, if the product is determined to be defective, an RMA number will be issued.
