T3CVK7720D (Trove3) Enclosure Dimensions (H x W x D approximate):
2.00" (50.8mm)
1.25" (31.8mm)
1.25" (31.8mm)
1" Conduit
3/4" Conduit
G
G
1.25" (31.8mm)
- 9 -
36.12" x 30.125" x 7.06" (917.5mm x 768.1mm x 179.3mm)
7.12" (222.3mm)
1" Conduit
3/4" Conduit
1.07"
(27.2mm)
14.01" (355.9mm)
1" Conduit
3/4" Conduit
3/4" Conduit
1" Conduit
8.75" (222.3mm)
2"
(50.8mm)
9.5" (241.3mm) 9.5" (241.3mm)
1.78" (45.2mm)
1.5" Conduit
2" Conduit
1.75" Conduit
30.12" (768.1mm)
14.01" (355.9mm)
8.62" (219mm) 8.75" (222.3mm)
1.55" (39.4mm)
1.5" Conduit
1.75" Conduit
1" Conduit
3/4" Conduit
7.06" (179.3mm)
