Access & Power Integration
Altronix/CDVI Kits
Models Include:
T1CVK34
4 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove1 enclosure with TC1 Altronix/CDVI backplane
- One (1) AL600ULXB - Power Supply/Charger
- One (1) ACM4 - Fused Access Power Controller
T2CVK710
10 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TCV2 Altronix/CDVI backplane
- One (1) AL1024ULXB2 - Power Supply/Charger
- One (1) ACM8 - Fused Access Control Module
- One (1) ACM4 - Fused Access Control Module
- One (1) PD8UL - Fused Power Distribution Module
T3CVK7720
20 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove3 enclosure with TCV3 Altronix/CDVI backplane
- Two (2) AL1024ULXB2 - Power Supply/Chargers
- Two (2) ACM8 - Fused Access Control Modules
- One (1) ACM4 - Fused Access Control Module
- One (1) PD8UL - Fused Power Distribution Module
- One (1) RSB2 - Rocker Switch Bracket with
Two (2) Rocker Switches (Not evaluated by UL)
All components of these Trove kits are UL Listed sub-assemblies.
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. TCVLK_052423
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
T1CVK34D
4 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove1 enclosure with TC1 Altronix/CDVI backplane
- One (1) AL600ULXB - Power Supply/Charger
- One (1) ACM4CB - PTC Access Power Controller
T2CVK710D
10 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TCV2 Altronix/CDVI backplane
- One (1) AL1024ULXB2 - Power Supply/Charger
- One (1) ACM8CB - PTC Access Control Module
- One (1) ACM4CB - PTC Access Control Module
- One (1) PD8ULCB - PTC Power Distribution Module
T2CVK3310
10 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TCV2 Altronix/CDVI backplane
- Two (2) AL600ULXB - Power Supply/Chargers
- Two (2) MOM5 - PTC Power Distribution Modules with Fire Alarm Interface
T3CVK7720D
20 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove3 enclosure with TCV3 Altronix/CDVI backplane
- Two (2) AL1024ULXB2 - Power Supply/Chargers
- Two (2) ACM8CB - PTC Access Control Modules
- One (1) ACM4CB - PTC Access Control Module
- One (1) PD8ULCB - PTC Power Distribution Module
- One (1) RSB2 - Rocker Switch Bracket with
Two (2) Rocker Switches (Not evaluated by UL)
More than just power.™
Advertisement
Related Manuals for Altronix TROVE T1CVK34
Summary of Contents for Altronix TROVE T1CVK34
- Page 1 4 Door Kit with PTC Outputs Fully assembled kit includes: Fully assembled kit includes: - Trove1 enclosure with TC1 Altronix/CDVI backplane - Trove1 enclosure with TC1 Altronix/CDVI backplane - One (1) AL600ULXB - Power Supply/Charger - One (1) AL600ULXB - Power Supply/Charger...
-
Page 2: Configuration Chart
Overview: Altronix Trove CDVI kits are pre-assembled and consist of Trove enclosures/backplanes with factory installed Altronix power supply/chargers and sub-assemblies. These kits also accommodate various combinations of CDVI Atrium A22K/A22NB/ADH10 boards for up to twenty (20) doors in a single enclosure. - Page 3 3. Fasten backplane to Trove2 enclosure utilizing pan head screws (provided). Fig. 2 Fig. 2a TRIGGER INPUT IN GND IN GND IN GND IN GND Altronix ACM4(CB) Altronix AL600ULXB Spacer LED1 LED2 LED3 LED4 MAIN NC C NO COM NC C NO COM...
- Page 4 Please make sure that they are mounted correctly, as shown in Fig. 3 below. 3. Fasten backplane to Trove2 enclosure utilizing pan head screws (provided). Fig. 3 Fig. 3a RJ45 Jack Altronix AL1024ULXB2 Spacer CDVI - A22K/A22NB/ADH10 AC DELAY Backplane...
- Page 5 3. Fasten backplane to Trove2 enclosure utilizing pan head screws (provided). Fig. 4 OFF - 24V ON - 12V Fig. 4a RJ45 Jack Altronix AL600ULXB Spacer CDVI - A22K/A22NB/ADH10 AC DC BAT BAT FAIL NC C NO NC C NO AC FAIL Backplane...
- Page 6 Please make sure that they are mounted correctly, as shown in Fig. 5 below. 3. Fasten backplane to Trove3 enclosure utilizing pan head screws (provided). Fig. 5 Fig. 5a RJ45 Jack RJ45 Jack CDVI - A22K/A22NB/ADH10 CDVI - A22K/A22NB/ADH10 Altronix AL1024ULXB2 Spacer AC DELAY RSB2 Backplane RJ45 Jack RJ45 Jack Altronix AL1024ULXB2...
- Page 7 T1CVK34 and T1CVK34D (Trove1) Enclosure Dimensions (H x W x D approximate): 18” x 14.5” x 4.625” (457mm x 368mm x 118mm) 14.5” (321.3mm) 7.25” (184.2mm) 1.45” (36.8mm) 1.95” (49.5mm) 4.5” (114.3mm) 13.0” (330.2mm) 1.25” (31.8mm) 1.25” (31.8mm) 1.5” (38.1mm) 1.5”...
- Page 8 T2CVK710, T2CVK710D and T2CVK3310 (Trove2) Enclosure Dimensions (H x W x D approximate): 27.25” x 21.5” x 6.5” (692.2mm x 552.5mm x 165.1mm) 21.50” (546.1mm) 2.00” (50.8mm) 2.00” (50.8mm) 5.25” (133.35mm) 5.25” (133.35mm) 3.5”(88.9mm) 3.5”(88.9mm) 0.685” (17.4mm) 1.25” Knockouts 0.5625” (14.3mm) (31.8mm) 1.77”...
- Page 9 T3CVK7720 and T3CVK7720D (Trove3) Enclosure Dimensions (H x W x D approximate): 36.12” x 30.125” x 7.06” (917.5mm x 768.1mm x 179.3mm) 9.5” (241.3mm) 9.5” (241.3mm) 2.00” (50.8mm) 7.12” (222.3mm) 1.25” (31.8mm) 1.55” (39.4mm) 1.78” (45.2mm) 1” Conduit 1.25” Conduit 1.5”...
- Page 10 Notes: - 10 - Trove CDVI ULXB Kits Installation Guide...
- Page 11 Notes: - 11 - Trove CDVI ULXB Kits Installation Guide...
- Page 12 Notes: Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty...
