Replacing the NVRAM PCI Card

Removing the Rear Cover Plate

To release the rear cover plate, turn the locking screw at the rear of the server
1
counterclockwise until the screw pops loose.
Figure 1. Removing the Cover Plate
Front Cover Plate
The cover is seated tightly on the chassis. Standing in front of the server, use the
2
heel of your hand to deliver a short, forceful thrust to the cover pad on the rear
cover plate of the server.
Slide the cover off and set it aside.
3
2
Copyright © 2009, Overland Storage, Inc. All rights reserved. Information in this document is subject to change without notice and does
not represent a commitment on the part of Overland Storage or any of its subsidiaries.
Cover Pad
Rear Cover Plate
Snap Server 18000
Locking Screw
