Overland Storage Snap Server 14000 Assembly

Motherboard tray assembly

The Snap Server

These instructions explain how to replace the motherboard tray assembly on the

Snap Server.

Replacement Part Inventory

Before you begin, make sure you have the following items from the package

containing the motherboard tray assembly:

• The motherboard PCA with DIMM, CPU, and mounting tray in an anti-static bag

• Server ID label

• Phillips screwdriver

To remove and replace the motherboard tray assembly, you perform the following

tasks:

• Shut down the server and disconnect the power cords and SCSI and Ethernet

connectors

• Remove the old motherboard tray assembly

• Remove the SCSI and Ethernet cards from the old motherboard

• Install the SCSI and Ethernet cards on the new motherboard

• Insert the new motherboard tray assembly

• Reattach the power cords and SCSI and Ethernet connectors

• Restart the server

Field Service Documentation

not represent a commitment on the part of Overland Storage or any of its subsidiaries.

14000 Motherboard Tray Assembly

Snap Server 14000
