Pole Mount Laptop Holder
Instruction Manual
SKU: MOUNT-PL1A-LAP3
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-pl1a-lap3
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-PL1A-LAP3
Summary of Contents for Vivo MOUNT-PL1A-LAP3
- Page 1 Pole Mount Laptop Holder Instruction Manual SKU: MOUNT-PL1A-LAP3 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-pl1a-lap3 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 ASSEMBLY STEPS STEP 1 OPTION A: 28mm - 45mm (1.1” - 1.77”) Pole Slide the mount (A) onto the pole and tighten bolts using the 6mm Allen wrench (F). Install the cable clip (E) to the mount. OPTION B: 46mm - 60mm (1.8” - 2.36”) Pole Remove the pre-installed clamping bolts from the mount (A) and replace with M8x70 bolts (D).
- Page 4 STEP 2: FOR LAPTOPS OPTION A: Laptop Installation Place tray arms (H) underneath each side of the laptop tray (G), aligning square holes in arms with the edge and long slot on each side. Insert clips (I) through top to secure the arms, making sure all 4 locks on each clip are engaged with square holes in the arms.
- Page 5 STEP 2: FOR LAPTOPS (Continued) Release locks on the underside of the tray arms (H). Extend arms, place laptop on the tray, then adjust arms to fit the width of the laptop. Engage locks to secure the laptop. If using a thicker laptop, turn the front bumpers to the upward position for additional support.
- Page 6 STEP 2: FOR MONITORS OPTION A: Flat Back Monitor Attach VESA plate (B) to monitor using 12mm screws (M-A, M-C) with washers (M-E). OPTION B: Curved / Recessed Back Monitor Attach VESA plate (B) to monitor using 16mm screws (M-B, M-D) with washers (M-E) and spacers (M-F).
- Page 7 STEP 2: FOR MONITORS (Continued) Adjust the tilt and swivel joints with the Allen wrench (F). Use the cable clip to organize cables. Adjust the monitor position as desired.
- Page 8 - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! 309-278-5303 AVG. RESOLUTION TIME : 5M 4S (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
