3. Push Button Functions with LED Displays

a. Standard Push Button Configuration (Transmitter Toggle)
Set the transmitter toggle (latching output relay) function by adjusting the 8-position
function dip-switch located on the backside of the transmitter encoder board (refer to Fig.
09 below). The LED 1 through LED 4 shown inside the shaded box (see below) illustrates
which LED on the transmitter will light up when the designated push button (PB5 - PB8)
is pressed.
LED 4 LED 3
1 00000000
2 00000101
3 00000110
4 00000111
5 00001000
* PB5...PB8 → Push button number
* Normal → Normal momentary contact
* LED 1...LED 4 → Transmitter toggled with designated LED Display
LED 2 LED 1
(Fig. 09)
DIP PB5 PB6
Normal Normal
Normal Normal
Normal Normal
Normal LED 2
LED 1 LED 2
PB7 PB8
Normal Normal
Normal LED 4
LED 3 LED 4
LED 3 LED 4
LED 3 LED 4
