TROUBLESHOOTING

8.1 Quick Troubleshooting
Problem
The appliance is on but is
not working. The red LED is
steadily lit (APC automatic
protection circuit tripped).
The appliance is on but is not
working. The red LED flashes
(APC automatic protection
circuit tripped).
The appliance is on but is not
working. The red and green
LED flash alternately.
During operation
whistling noise can be heard
coming from the
handpiece.
Possible Cause
Handpiece not connected to
the cord
Broken wire in the cord
Faulty handpiece
Tuning circuit malfunction
The insert is not present or
not correctly tightened on
the handpiece.
The insert is worn, damaged,
or deformed.
The connector of the
handpiece or cord is wet.
Power supply too low.
Power supply too high.
Potentiometer not
connected.
a faint
The insert is not correctly
scaler tightened on the handpiece
TROUBLESHOOTING
WARNING: Portable RF communication
equipment (including peripheral devices such
as antenna cables and external antennas)
must not be used closer than 30 cm to any
part of the COMPACT PIEZO P2K device,
including the cables specified by the
manufacturer. Otherwise, there may be
a performance degradation of these
appliances.
Connect the handpiece to
the cord
Contact your nearest
Authorised MECTRON
Service Centre
Contact your nearest
Authorised MECTRON
Service Centre
Contact your nearest
Authorised MECTRON
Service Centre
Unscrew and correctly re-
screw the insert
Replace the insert
Dry the connectors
Supply the correct power.
Supply the correct power.
Correctly connect the
potentiometer.
Unscrew the insert and screw
it back in correctly using the
Mectron torque wrench (See
Chapter 4.4 on page 24
of the Use and Maintenance
Manual)
Solution
